Foton Lovol 3ton 2m3 FL936h Small Front Wheel Loader with Pallet Fork

Acntruck Automobile Sales (Shanghai) Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Rated Load：1-3t
  • Transmission：Hydraulic - Mechanical
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：FL936H
  • Type：Medium-sized Loader
  • Rated Load(Kg)：3000
  • Operating Mass (Standard)(Kg)：10250
  • Bucket Capacity(M³)：2
  • Wheelbase(mm)：2880
  • Model(Weichai)：Weichai Wp6g125e22
  • Rated Power(Kw/Rpm)(Weichai)：92
  • Transport Package：Nude Packing
  • Specification：7090*2520*3200
  • Origin：Jiangsu, China
  • HS Code：842951000
  • Production Capacity：1000,PCS

Description

EngineModelWeichai WP6G125E22Max. torque(N·m)500Rated power(kW)92Rated rotational speed(rpm)2200Gearbox shiftFront:4 gears Rear:2 gearsMax. speed39Type17.5-25Ply rating12Steering angle38Operating modelMechanically controlSum of three items(s)9.2Fuel tank(L)170Hydraulic oil tank(L)120Foton Lovol 3ton 2m3 FL936h Small Front Wheel Loader with Pallet Fork
