Shantui Excavator Se215 with 0.9cbm Bucket Capacity for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Electric Drive
- Bucket Capacity：0.9cbm
Base Info
- Model NO.：SE215
- Size：Large-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Ground Clearance of Counterweight (mm)：1075
- Minimum Ground Clearance (mm)：470
- Tail Turning Radius (mm)：2925
- Track Length (mm)：4140
- Track Gauge (mm)：2200
- Track Width (mm)：2800
- Standard Track Shoe Width (mm)：600
- Turntable Width (mm)：2725
- Distance From Slewing Center to Tail (mm：2920
- Maximum Digging Height (mm)：10095
- Maximum Dumping Height (mm)：7190
- Maximum Digging Depth (mm)：6490
- EngineT Model：Qsb7 (China-III)
- Displacement (L)：6.7
- Rated Power (Kw/Rpm)：124,2050
- Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification：4915*3075*2800mm
- Trademark：shantui
- Origin：China
- Production Capacity：300piece,Month
Description
Basic Info.
Model NO. SE215 Size Large-Scale Certification CE, ISO9001: 2000 Condition New Ground Clearance of Counterweight (mm) 1075 Minimum Ground Clearance (mm) 470 Tail Turning Radius (mm) 2925 Track Length (mm) 4140 Track Gauge (mm) 2200 Track Width (mm) 2800 Standard Track Shoe Width (mm) 600 Turntable Width (mm) 2725 Distance From Slewing Center to Tail (mm 2920 Maximum Digging Height (mm) 10095 Maximum Dumping Height (mm) 7190 Maximum Digging Depth (mm) 6490 EngineT Model Qsb7 (China-III) Displacement (L) 6.7 Rated Power (Kw/Rpm) 124/2050 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 4915*3075*2800mm Trademark shantui Origin China Production Capacity 300piece/MonthProduct Description
Shantui Excavator SE215 With 0.9Cbm Bucket Capacity For SaleContact Ash for more information__________________________________________________________________________________
CHARACTERISTICOptional attachments
Breaking hammer
Ripper
Timber grab
Hydraulic tamper
Stone grab
Quick change coupling
Breaking hammer pipeline
Optional equipment of machineOil bath type air prefilter Cab warning lamp Body rear camera
Cab overhead protective net Cab front upper protective net Cab front lower protective net
700mm track shoe 800mm track shoe Electric refueling pump
Machine guardrail Hydraulic shear
Quick and convenient maintenancesSupported by two cylinders, the backward-opening engine hood features handy opening, large opening angle, and easy maintenances.
The electric parts are centrally arranged to ease the checking and maintenances.
The filling of coolant, the replacement of air filter element, and the power master switch are easily accessible.
The parallel radiator effectively avoids the overheating and eases the cleaning.
The fuel filter element, engine oil filter element, and pilot filter element are centrally arranged so that all maintenances and replacements can be completed from on same position
The high-precision fuel filter element features powerful fuel adaptability and the electric fuel pumping function is provided for automatic fuel refilling and easy start.
Spacious and comfortable operating environmentThe colors of the injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.
The control devices are reasonably arranged to realize large space, broad vision, and convenient and comfortable operations.
The high-power A/C system and the air cushioned seat guarantee comfortable driving/riding.
Intelligent electronic control and optimal power controlThe intelligent control system realizes high match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.
The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Drive sprockets, idlers, track rollers, carrier rollers, and tracks30 years of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and industry's leading technologies
The mature and high-quality forging and heat treatment processes guarantee stable and reliable quality.
Enhanced working deviceThe design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
High-end system configurationIndustry's leading high-adaptability turbocharged engine.
The high-end reliable hydraulic system configuration and full-electronic-control positive flow hydraulic system reduce the energy loss and guarantee high efficiency and energy-saving and good motion coordination.
PARAMETER| Comparative item | SE215 (Standard version) |
| Overall dimensions | |
| Overall length (mm) | 9625 |
| Ground length (During transport) (mm) | 4915 |
| Overall height (To the top of boom) (mm) | 3075 |
| Overall width (mm) | 2800 |
| Overall height (To top of cab) (mm) | 3055 |
| Ground clearance of counterweight (mm) | 1075 |
| Minimum ground clearance (mm) | 470 |
| Tail turning radius (mm) | 2925 |
| Track length (mm) | 4140 |
| Track gauge (mm) | 2200 |
| Track width (mm) | 2800 |
| Standard track shoe width (mm) | 600 |
| Turntable width (mm) | 2725 |
| Distance from slewing center to tail (mm) | 2920 |
| Working range | |
| Maximum digging height (mm) | 10095 |
| Maximum dumping height (mm) | 7190 |
| Maximum digging depth (mm) | 6490 |
| Maximum vertical digging depth (mm) | 5915 |
| Maximum digging distance (mm) | 9860 |
| Maximum digging distance at ground level (mm) | 9675 |
| Working device minimum turning radius (mm) | 2970 |
| Maximum lifting height of bulldozer blade (mm) | - |
| Maximum digging depth of bulldozer blade (mm) | - |
| Engine | |
| Model | Cummins QSB7 (China-III) |
| Type | 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
| Displacement (L) | 6.7 |
| Rated power (kW/rpm) | 124/2050 |
| Hydraulic system | |
| Type of hydraulic pump | Variable displacement duplex plunger pump |
| Rated working flow (L/min) | 2x213 |
| Bucket | |
| Bucket capacity (m³) | 0.9 |
| Swing system | |
| Maximum swing speed (r/min) | 11 |
| Brake type | Mechanically applied and pressure released |
| Digging force | |
| Bucket arm digging force (KN) | 135/146 |
| Bucket digging force (KN) | 99/107 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 20800 |
| Ground pressure (kPa) | 47.5 |
| Traveling system | |
| Traveling motor | Axial variable displacement plunger motor |
| Traveling speed (km/h) | 3.15/5.15 |
| Traction force (KN) | 214 |
| Gradeability | 70%(35°) |
| Tank capacity | |
| Fuel tank capacity (L) | 330 |
| Cooling system (L) | 28 |
| Engine oil capacity (L) | 22 |
| Hydraulic oil tank/system capacity (L) | 270/400 |
