• Model NO.：ST4000
• Travel Speed：35cm,s
• Centrifugal Force：40KN
• Certification：EPA, CE, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Engine：Changchai Zn390b
• Drum Width：1200mm
• Drum Diameter：720mm
• Steering Method：Hydraulic Steering
• Fuel Tank Capacity：42L
• Water Tank Capacity：140L
• Hydraulic Oil Tank：42L
• Walking Speed：0-10km,H
• Power：28.5lw
• Vibration Drum：Double Drum
• Weight：3500kg
• Transport Package：Wooden Package
• Specification：2380*1355*1955mm
• Origin：China
• HS Code：8429401900
• Production Capacity：5000 Set,Year

ST4000 ROAD ROLLER is mainly used to compress on the asphalt, sand soil and gravel. It is also used to compress on track in the school and planish the lawn. This is the latest model of light duty rollers in the domestic.

Product characteristics

Double motors drive, hydraulic steering and vibrate, fully hydraulic roller.

1. Imported Sauer hydraulic variable plunger pump, drives the machine stepless speed walking.

2. Double Poclain plunger motors drive the machine walking.

3. Imported brand motor drives the steel drum vibrating.

4. Extra-large plastic water tank, free from corrosion and convenient for the water-spraying.

5. Double control levers with vibration button, makes the compaction of edge easy.

6. Electrically controlled water-spray, high efficient and water-saving.

7. Wear-resistant scraper can be lift and fixed during transportation.

8. LED lamp at front and rear for the convenience of night construction.

ST4000ENGINE EngineChangchai ZN390BEngine typeThree cylinder, Vertical, water-cooled, four-stroke, dieselNumber of cylinders3Output power (KW)28.5Rating speed(RPM)2600Fuel consupmtion(G/KWH)240Lubricating oil volume(L)5DRIVING Electrical equipment(V)12Drive modeVariabledisplacement pump, stepless speed change, two wheels drive,motor parallelWalking speed (KM/H)0-10Theoretical climbing ability(%)30/40(vibration on/off)STEERING Swing angle(°)30Steering modeHydraulic cylinder, articulated steeringSteering systemSwing articulatedEXCITING SYSTEM Vibration wheelFront/ Rear/ DoubleDrive formHydraulic MotorsVibration frequency (HZ)60Vibration amplitude (MM)0.5Exciting force(KN)35SPRINKLING SYSTEM Water spray formIntermittent pressure water sprayCAPACITY Hydraulic oil capacity(L)42Fuel capacity(L)42Water tank capacity (L)140SIZE Working width(MM)1370Overall length(MM)2480Machine height(MM)2670Turning radius(outer)(MM)4130Ground clearance(MM)385Wheel track(MM)1720Drum size720*1200mm*2Drum thickness(MM)16Wheel offset(MM)50WEIGHT Weight(KG)3500Static load(N/CM)135/125
Feedback from clients:



Packaging & Shipping


Company Information:

Shandong Storike Engineering  Machinery Co., Ltd is specialized in the sales and production of small road roller, compact ram, mobile lighting car, hydraulic power station, troweling machine and other construction machine. Our products are widely used in municipal and highway pavement road roller maintenance, small area compacting and depressed trough and so on. Our equipment is favored by many construction companies and have a large market in China. More and more trading companies purchase equipment from our plants, so we decide to enter world market with more favorable price to shape our product brand and provide the best after-sale service. If you are interested in our machine, contact us!



STORIKE Clients:
