Highway Guardrail Hydraulic Pile Driver Machine Guardrail Pile Driver
Ji Ning Hengwang Mining Machinery Co., Ltd.- After-sales Service：Yes
- Warranty：Yes
- Certification：ISO, CE
- Condition：New
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
Base Info
- Model NO.：HWH940L
- Model：Hwh940L
- Engine Power(Kw)：76
- Chassis Body Width(mm)：1980
- Rotating Motor Torque(Nm)：1600
- Drive Way：Four-Wheel Drive
- Vehicle Weight(Kg)：5200(13-8)
- Mast Stroke(mm)：2000
- Loader Model：Zl940L
- Drilling Depth(mm)：1650
- Work Plan(mm)：700-3130
- Drill Rod Diameter(mm)：68,75,85
- Gear Pump Flow(Ml/Min)：40-50
- Piling Efficiency(mm/Min)：1500,2000,2500
- Walking Speed(Km/H)：0~26
- Engine Model：Yn38gbz
- Transport Package：Stande Package
- Specification：4700*2550*2900mm
- Trademark：HW
- Origin：Shangdong China
- HS Code：8429510000
- Production Capacity：50000set,Year
Description
HWH940L Main technical parameters
Working dimension(mm)
4700*2550*2900
Engine power(kw)
76
Transport dimension(mm)
6115*2400*2850
Drive way
four-wheel drive
Chassis body width(mm)
1980
Rotating motor torque(Nm)
1600
Vehicle weight(kg)
5200(13-8)
Mast stroke(mm)
2000
Loader model
ZL940L
Drilling depth(mm)
1650
Hydraulic hammer model
AR68/AR75/AR85
Drilling diameter(mm)
0-300
Work flow(Lmin)
40-70/50-90/60-100
Rail frame inclination0
left35right10
Impact frequency(bmp)
500-900/400-800/400-800
Adjust the angle0
±10
Work plan(mm)
700-3130
Hydraulic system pressure(Mpa)
16-20
Drill rod diameter(mm)
68/75/85
Gear pump flow(mL/min)
40-50
Hammer force(T)
4-7/6-8/7-14
Sliding stroke left and right(mm)
0-450
Piling efficiency(mm/min)
1500/2000/2500
Height from ground(mm)
7203100
Walking speed(km/h)
0~26
Air compressor displacement(m3)
13
Braking method
Air cap oil four-wheel disc brake
Air compressor pressure(MPa)
0.8
Engine model
YN38GBZ
Gradeability0
19
