• Model NO.：HQ916M
• Origin：Shandong, China
• HS Code：84295100
• Production Capacity：8000 Units , Year

Basic Info.

Model NO. HQ916M Origin Shandong, China HS Code 84295100 Production Capacity 8000 Units / Year

Product Description

Wheel Loader HQ916 manufactured on the production line which equiped  cutting machines,CNC flame cutting machines as well as advanced bending,stamping,welding and processing equipments.

All structure parts produced by the advanced equipment, this keep the very quality stable .

Rated Bucket Capacity	0.9m3	Transmission Type	Counter Shaft Power-shift
Rated Load Capacity	1600KG	Gear Number	Two Advance Gears, Two Reverse Gears
Overall Weight	4870KG	Max. Speed	24km/h
Auto Flatting Function of Bucket	Have	Front and Rear Drive Axles
Static Tipping Load	3735kgf	Main Drive Type	Spiral Bevel Gear One-stage Reduction Type
Max. Breakout Force	51KN	Hub Reduction Type	Single Row of Planetary Gears
Max. Traction Force	3450kgf	Tyre
Max. Gradeability	30°	Specification	16/70_20
Lifting Time of Bucket	4.8s( (Full Load)	Air Pressure of Front Tyre	220kpa
Fall Time of Bucket	3.3s( (Full Load)	Air Pressure of Rear Tyre	180kpa
Dumping Time of Bucket	1.1s	Steering System
Overall Dimensions		Type	Load Sensing Steering Gear
L*W*H (mm)	5182x1910x2712	Turn Angle	35°±1 right and left
Engine	Weichai Diesel Engine Plant	Min. Turning Radius	4367mm
Model	ZH4100K14_3	Hydraulic System
Type	Straight Air-cooling Four-stroke Direct-injection	Distribution Valve	ZL20E_04T.QW
Cylinder Number-Inner Diameter*Stroke	4_100x125	Working Pump	CBG2063
Max. Torque	270Nm	Brake System
Rated Power	45KW	Service Brake	Hydraulic Four-wheel Caliper Disc Type
Min. Fuel Consumption	≤243g/.kw .h	Parking Brake	Flexible Shaft Control External Drum Type
Rated Rotational Speed	2400r/min	Emergency Brake	Hydraulic Four-wheel Caliper Disc Type
Drive System		Fuel Capacity	80L
Torque Converter Model	YJ1_26501	Pressure of Hydraulic System	160Mpa
Type	Single-stage Single-phase Three-element	Dumping Height	2330
