• Model NO.：W136II
• Type：Small Loader
• Shovel Loader：Wheel Loader 3ton
• Dumping Height：3060mm
• Bucket Capacity：1.8-2.2m3
• Operation Weight：10500kg
• Engine Brand：Cummins or Deutz
• Gearbox：Zl30 Planet Type
• Gear Shifts：F2,R1
• Service Brake：Air Active Oil, Brake Shoe with Disc
• Tyre Size：17.5-25
• Cabin：Air Conditioned
• Transport Package：in Container
• Specification：ISO CE Gost-R
• Trademark：WORLD
• Origin：China
• HS Code：84295100
• Production Capacity：6000PCS,Year

Basic DataBucket Capacity1.8m³Rated Load3200kgTravelling SpeedForward 1st0-12km/hForward 2nd0-40km/hReverse 1st:0-17km/hMax.Traction97kNMax.Break Out Force100kNMin.Turn Radius (outside tyre)5376mmMax. Dumping Height3060mmMax. Reach1008mmTotal Hydraulic Cycle Time≤10.3sFull Bucket Lifting Time≤5.6sWheel Base2750mmDimensions (LxWxH)6970x2450x3286mmMin. Clearance Over Ground360mmOperating Weight10500kgDiesel EngineModelCummins 6BT5.9 or Yuchai YC6B125TypeDirect injection, water cooling, 4 strokesRated Output97/92kWRated Speed2200rpmMax. Torque560N.m/460N.mTransmission Hydraulic Torque Converter ModelSingle stage, two phase, four componentsTransmission Type2 forward and 1 reverse gears/hydraulic power shift, planet typeMax. Permissible Temp.120Transaxle & TyreDrive System4 wheel driveType of main ReducerSpiral bevel gear, single stageType of hub ReducerPlanet gearTyre Size17.5-25Pressure Of Tyre0.28-0.32MPaWorking Hydraulic SystemWorking Pump TypeGear PumpSystem Working Pressure16MPaLifting Cylinder Bore x Stroke125x816mmTilting Cylinder Bore x Stroke140x553 mmSteering SystemTypefull hydraulic power steering systemSteering Pump TypeGear PumpMax. Working Pressure10MPaSteering Cylinder Bore x Stroke80x380mmMax. Steering Angle±36 ºBrake SystemTypeCaliper disc brake, air over oil activate, 4 wheel brakeDrive Brake System Pressure0.71-0.784MPaParking BrakeHand brake, drum typeOil Injection CapacityFuel Tank170LEngine Oil15LTransmission30LHydraulic Oil Tank170LTransaxle30L
