• Model NO.：Xs142j
• Travel Speed：40cm,s
• Centrifugal Force：15KN
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Operating Weight：14000kg
• Weight on Front Drum：7000kg
• Static Linear Pressure：322n,Cm
• Speed I：2.7
• Theoretical Gradeability：30%
• Min. External Turning Radius：6800mm
• Steering Angle：30
• Excitation Force：274,137kn
• Engine Model：Sc5d125g2b1
• Transport Package：Container
• Specification：6100x2350x3200mm
• Origin：China
• HS Code：8701909000
• Production Capacity：50 Per Month

ModelUnitXS142JOperating weightkg14000Weight on front drumkg7000Static linear pressureN/cm322Speed rangekm/h Speed I 2.7Speed II 4.8Speed III 10.5Theoretical gradeability%30Min. external turning radiusmm6800Steering angle°±30Oscillating angle°±11Vibration frequencyHz28Nominal amplitude (high/low)mm1.9/0.95Excitation force (high/low amplitude)kN274/137Engine model SC5D125G2B1TypeWater cooled, pressurizedWater cooled, pressurizedMax. powerkW92@2200r/minEngine oil consumptiong/kW.h230Hydraulic oil tank capacityL170Fuel tank capacityL180
