• Model NO.：HDL5270THB
• Concrete Output：120 M3,H
• Max. Vertical Reach：37 M
• Engine Rated Power：265 Kw ,1, 800 Rpm
• Transport Package：Nude Packing
• Specification：CE, ISO9001
• Trademark：LiuGong
• Origin：China(Mainland)
• HS Code：8705909090
• Production Capacity：100sets, Month

CHASSIS
HYDRAULIC SYSTEM
Chassis Model
 ISUZU CYZ51Q
Hydraulic System Type
open loop
Emission Regulation


Emission Regulation


System Working Pressure
32 MPa
Engine rated Power
265 kW (360 hp) @ 1,100 rpm
Main Hydraulic Pump
Rexroth
Engine Displacement
9.7 L
Main Hydraulic Pump Type
A11VLO190
Driving Type
4x2
Main Hydraulic Pump

Displacement
190 ml/r
Wheelbase
5,000 mm
Main Hydraulic Directional Valve
Vickers
Max. Running Speed
90 km/h
Oil Suction&Return Filter
Sofima
Min. Turning Radius
8.8 m
Multi-Way Valve
have
Approach/Departure Angle
20.5/10.5°
Pressure Relief Valve
Lixin
Tyre Type
11.00-20
Hydraulic Seals
Parker
BOOM SYSTEM
Hydraulic Hose
Manuli
Max. vertical reach
23.1 m
Hydraulic Oil Tank Capacity
400L
Max. horizontal reach
19.1 m
Water Tank Capacity
  285 L
Reach depth
12.2 m
Water pump
Black cat
Unfolding height
6.6 m
DIMENSIONS&WEIGHT
Boom control mode
Manual, wire and wireless remote control are all available
Overall Length
9,764 mm
Boom type
Z
Overall Width
2,490 mm
Arm section articulation
90/180/256
Overall Height
3,620 mm
Slewing range
365°
Overall Net Weight
15,820 kg
Front Outriggers spread
4,880 mm
PUMPING SYSTEM
Rear Outrigger spread
2,280 mm
Concrete Valve
S valve
End hose length
3m
Concrete Output
110/65 m3/h
Arm attached pipeline diameter
125 mm
Concrete Pressure
7/12 MPa
ELECTRICAL CONTROL SYSTEM
Hydraulic Strokes
15/25 min
Power Supply
Apollo 12V 16H×2
High And Low Pressure

Exchanger
available
Control Module
Hirschman IFLEX C3-H
Hydraulic Cylinder Bore/Stroke
Φ140/1800
Working Voltage
DC 24 V
Concrete Cylinder Bore/Stroke
Φ230/1800 mm
Relay
Omron
Hopper Charge Height
≤1,500
Proximity Switch
Bedook
Concrete Hopper Capacity
0.7 m3
Wireless Remote Controller
HBC
Concrete Slump
120-230 mm
