• Model NO.：GR2153 motor grader
• Transmission：Hydraulic - Mechanical
• Walking Mode：Wheeled
• Type：Large Grader
• After-Sales Service Provided：Overseas Service
• Drive Type：Rear-Axle Drive
• Engine Model：Qsb6.7
• Rated Power/Speed：164kw,2000rpm
• Dimension：8970X2625X3420mm
• Operating Weight：16500kg
• Max. Gradeability：25%
• Tire Inflation Pressure：260kpa
• Working Hydraulic Pressure：20MPa
• Transmission Pressure：1.3~1.8MPa
• Tractive Force：85kn
• Maximum Lift Above Ground：400mm
• Maximum Depth of Cutting：500mm
• Moldboard Width X Height：4270X610mm
• Blade Cutting Angle：28-70degree
• Transport Package：Naked in Container
• Specification：CE
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8429209000
• Production Capacity：5000PCS,Year

ItemGR2153Basic parametersEngine modelQSB6.7Rated power/speed164kW/2000rpmOverall dimension (standard)8970x2625x3420Total weight (standard)16500 kgTire specification17.5-25Ground clearance (front axle)430mmTread2156mmSpace of front and rear axles6219 mmSpace of middle and rear wheels1538 mmPerformance parametersForward velocity5,8,11,19,23,38km/hReverse speed5,11,23km/hTractive effort f=0.7585 kNMaximum gradeability≥25%Tire inflation pressure260kPaWorking system pressure20MPaTransmission pressure1.3-1.8MpaWorking parametersMaximum steering angle of front wheel±48°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±15°Maximum oscillating angle of equilibrium box±15°Maximum steering angle of frame±27°Minimum turning radius7.3mScrape knifeMaximum lift height400mmMaximum cutting depth500mmMaximum tilt angle90°Cutting angle28°-70°Angle of revolution360°Length & chord height4270x610mmOil filling amountCoolant50LFuel tank280LEngine24LTransmission38LBalancing box46LDrive axle28LHydraulic oil110L
