Cheap Price 215HP Gr215 Motor Grader with Front Dozer and Rer Ripper

Shanghai Super-Above Industry Holdings Co., Ltd.
  • Condition：New
  • Application：Railway, Mine, Farmland, Highway

Base Info

  • Model NO.：GR215 motor grader
  • Transmission：Hydraulic - Mechanical
  • Walking Mode：Wheeled
  • Type：Large Grader
  • After-Sales Service Provided：Overseas Service
  • Drive Type：Rear-Axle Drive
  • Engine Model：6CTA8.3-C215
  • Rated Power/Speed：160kw,2200rpm
  • Dimension：8970X2625X3420mm
  • Operating Weight：16500kg
  • Max. Gradeability：20%
  • Tire Inflation Pressure：260kpa
  • Working Hydraulic Pressure：16MPa
  • Transmission Pressure：1.3~1.8MPa
  • Tractive Force：87kn
  • Maximum Lift Above Ground：450mm
  • Maximum Depth of Cutting：500mm
  • Moldboard Width X Height：4270X610mm
  • Blade Cutting Angle：28-70degree
  • Transport Package：Naked in Container
  • Specification：CE
  • Trademark：Super-above
  • Origin：Jiangsu, China
  • HS Code：8429209000
  • Production Capacity：5000PCS,Year

Description

Oil filling amountCoolant50LFuel tank280LEngine24LTransmission38LBalancing box46LDrive axle28LHydraulic oil110LCheap Price 215HP Gr215 Motor Grader with Front Dozer and Rer Ripper
