• Model NO.：SEM636D
• Type：Medium-sized Loader
• Bucket Capacity：2.5m3
• Rated Power：92kw
• Load Capacity：3t
• Machine Weight：10300kg
• Transport Package：Nude Package
• Specification：8225× 3016× 3515mm
• Trademark：Oriemac
• Origin：China
• HS Code：8429510000
• Production Capacity：100units Per Month

ItemUnitParamsMain SpecificationsRated Loadkg3,000Operating Weight with Standard Bucketkg10,200Bucket Capacitym³1.5-2.5Wheel Basemm2,740Overall Dimensionmm7,422*2,354*3,182Max. Drawbar ForceKN97Breakout ForceKN113Dump Clearancemm2,989B-Pin Height 3,917TransmissionTransmission Type Countershaft, power shiftTransmission Gears F4/R2Torque Converter Type Single stage, 3 elementsMaker & Type TR100Forward I/Reverse I 7.9/7.9Forward II/Reverse II 14/14Forward III/Reverse III 25/NAForward IV/Reverse IV 39/NAAxleMain Drive Type Spiral bevel gear, single stageFinal Drive Reduction Type Planetary type, single stagRear - Oscillating +/- ±12EngineModel WP6G125E332Rated PowerkW92Rated Speedr/min2,200DisplacementL6.7Implement HydraulicImplement System Type Open centerBoom Raise Times4.65Hydraulic Cycle Times8.34System Presure SettingMpa18Brake SystemService Brake Dry & caliper, air to oil controlParking Brake Drum/ShoeSteering Sys temSystem Type Shared flowSteering Pump Type Gear pumpSystem Presure Setting 14Steering Angle (L/R)Mpa36±1TiresSize 17.5-25Type BiasLayer 12Txtured Type L-3
