• Model NO.：Ltc212
• Condition：New
• Operating Mass (Kg)：12000kg
• Front Axle Load (Kg)：6000kg
• Rear Axle Load (Kg)：6000
• Static Linear Load (N/Cm)：286
• From of Frame：Fork-Type
• Travel Speed (Km/H)：0-12
• Turning Radius (mm)：7000
• Drum Diameter (mm)：1350
• Drum Width (mm)：2100
• Drum Rim Thickness (mm)：20
• Wheelbase (mm)：3717
• Diesel Model：Cummins 6bt5.9
• Transport Package：Nude Packing
• Specification：5900 * 2280*3050mm
• Origin：Jiangsu, China
• HS Code：84294019
• Production Capacity：1000,PCS

ModelLTC212Operating mass (kg)12000Front axle load (kg)6000Rear axle load (kg)6000Static linear load (N/cm)286From of frameFork-typeCrabwise movement distance (mm)±170Vibration amplitude
 (mm)High amplitude0.8Low amplitude0.4Vibration frequency (Hz)High amplitude40Low amplitude46Centrifugal force (kN)High amplitude160x2Low amplitude90x2Travel speed (Km/h)0-12Turning radius (mm)7000Grade ability (%)40Steering angle (°)±30Vibrating wheel transverse swing angle(°)±8Drum diameter (mm)1350Drum width (mm)2100Drum rim thickness (mm)20Wheelbase (mm)3717Min. Ground clearance (mm)324Diesel modelCummins 6BT5.9Diesel power (kw)110Diesel speed (rpm)2300Water tank capacity (L)2x600Type of Water sprayPressureFuel tank capacity (L)154Hydraulic tank capacity (L)65Overall dimension (mm)5056x2250x3300CoveringAir-conditioning cabin
