• Vibrating Amplitude：1.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Red
• Concrete Slump Range：8~23cm
• Theoretical Pumping Times：24~27min
• Theoretical Output：150m3,H
• Reach Height：38m
• Emission Standard：Eruo III
• Max. Speed：85km,H
• Wheelbase：4600+1350mm
• Hopper Capacity：550L
• Distribution Valve：S Valve
• Hydraulic Oil Cooling：Wind Cooling
• Recommended Concrete Slump：12-23m
• Pipe Diameter：125mm
• Transport Package：Nude
• Specification：36350kg
• Trademark：ZOOMLION
• Origin：Hunan, China
• Production Capacity：100units,Week

Pump UnitMax. Theor. output m³/h120/80Max. Theor. concrete output PressureMPa7/11Rated working pressure MPa35Pumping frequency min-124/15Hopper    capacity L550Filling height mm1540Hydraulic system type opened loopDistribution valve S valveOil cylinder dia.×strokemmφ130×2100Concrete cylinder    dia.×stroke           mmφ230×2100Hydraulic oil cooling Wind coolingRecommended concrete slump                    cm12~23Max. aggregate dimension                    mm40Boom SectionStructure type 36X-5ZPlacing depth                                m35.5Max. horizontal distance                       m35.15Max. placing depth                           m23.13Slewing angle ±350°Boom number 5The length of boom section                        mm7700/5950/5950/5950/5950Sections folding angle 90°/180°/230°/180°/250°Pipe diameter                                mm125End hose length                             mm3000Min. height of opening placing boom        mm8520Outriggers span     (front×rear×side)  mm6030×5950×7300Upper StructureUpper Structure Mass         kg25000Dimensions(L×W×H)mm10740×2500×3886
