Pneumatic Tyre Road Roller Compactor Hot Sale Cheap Price for Discount
Sinoway Industrial (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Rubber Wheel
- Axle：F5,R6
- Grinding Wheel Type：Smooth Rubber Tyre
- Compaction Depth：40cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：SW01826
- Travel Speed：40cm,s
- Centrifugal Force：40KN
- Certification：ISO 9001:2000, ISO 9001:2008, ISO14001
- Condition：New
- Diesel Engine：Cummins
- Tire Number：F4+R5
- Tire Size：11.00-20
- Compaction Width：2790 mm
- Warranty：One Year
- Transmission：Mechanical
- Transport Package：Naked
- Specification：ISO2008
- Trademark：SINOWAY
- Origin：China
- HS Code：84294990
- Production Capacity：300 PCS,Month
Description
EngineModel Cummins 6BTA5.9 Type Six-cylinder,water-cooled turbocharged,mechanical injection Rated power 125kw Rated speed 2000rpm Transmission System Type Hydraulic drive Gradeability 20% Travelling speed (km/h) Forward/Reverse 0 - 14 Travelling pump Sauer/Rexroth piston pump Travelling motor Sauer/Rexroth piston motor Axle and Tyre Type of main reducer Spiral bevel gear Gear ratio 1:6.17 Final reducer Chain driven Chain gear ratio 1:2.17 Single tire load (F/R) 2400kg Tyre number (F+R) 5+6 Tyre size 11.00-20 Main Technical Specification Max. operating weight 26000Kg Min. operating weight 18000kg Average ground pressure 0.2 - 0.42MPa Tyre pressure 0.2 - 0.8MPa Compacting width 2790mm Vertical oscillation ± 100mm Steering System Type Hydraulic steering Working pressure 13MPa Steering cylinder 90 x 50 x 260mm Min. steering radius 8000mm Braking System Service brake Hydraulic brake Parking brake Oil cut-off brake Service Capacities Hydraulic tank 67L Gear box 10L Fuel tank 220L Engine crank case 16L Dimensions Overall length 4878mm Overall width 2800mm Overall height 3103mm Wheelbase 3800mm Ground clearance 300mm
