XCMG Official China New Series Motor Grader Gr2605II

XCMG E-Commerce Inc.
  • Certification：ISO, CE
  • Condition：New
  • Application：Highway
  • Transmission：Hydraulic
  • Engine Brand：Cummins
  • Unique Selling Point：Environmental, Energy-Saving, Large Power Engine

Base Info

  • Model NO.：GR2605II
  • Rated Power/Speed：194kw,2200rpm
  • Ground Clearance：620mm
  • Maximum Gradeability：25%
  • Transport Package：Comply with Export Packaging Requirements
  • Specification：9370*2800*3522mm
  • Trademark：XCMG
  • Origin：Jiangsu, China
  • Production Capacity：10000 Unit,Units Per Year

Description

ItemGR2605IIBasic parametersEngine modelQSB6.7Rated power/speed194kW/2200rpmOverall dimension (standard)9370x2800x3522Total weight (standard)19000 kgTire specification20.5-25Ground clearance (front axle)620mmSpace of front and rear axles6531 mmSpace of middle and rear wheels1622 mmPerformance
parametersForward velocity5,8,11,19,26,47km/hReverse speed5,11,26km/hTractive effort f=0.7599kNMaximum gradeability25%Tire inflation pressure350kPaWorking system pressure22MPaTransmission pressure1.85-2.2MpaWorking parametersMaximum steering angle of front wheel±48°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±15°Maximum oscillating angle of equilibrium boxforwards15°, Reverse15°Maximum steering angle of frame±20°Minimum turning radius7.9mScrape knifeMaximum lift height480mmMaximum cutting depth715mmMaximum tilt angle90°Cutting angle29°-69°Angle of revolution360°Length & chord height4270x610mmOil filling amountCoolant50LFuel tank270LEngine24LTransmission38LEquilibrium box170LDrive alex44LHydraulic oil190LRelated Products To Choose Online Service TeamXCMG Official China New Series Motor Grader Gr2605IICompany ProfileXCMG Official China New Series Motor Grader Gr2605IIXCMG Official China New Series Motor Grader Gr2605IIXCMG Official China New Series Motor Grader Gr2605IIXCMG Official China New Series Motor Grader Gr2605IIXCMG Official China New Series Motor Grader Gr2605IIXCMG Official China New Series Motor Grader Gr2605II
