XCMG Official Gr2205III Tractor Motor Grader
XCMG E-Commerce Inc.- Certification：Ce,ISO9001
- Condition：New
- Applicable Industries：Manufacturing Plant, Home Use, Construction Works
- Hydraulic Cylinder Brand：Undetermined
- Dimension(L*W*H)：9300*2625*3470
- After-Sales Service Provided：Engineers Available to Service Machinery Overseas
Base Info
- Model NO.：GR2205III
- Warranty：1 Year
- Hydraulic Valve Brand：Undetermined
- Hydraulic Pump Brand：Undetermined
- Engine Brand：Undetermined
- Forward Speed(Km/H)：45
- Reverse Speed(Km/H)：25
- Transport Package：Comply with Export Packaging Requirements
- Trademark：XCMG
- Origin：Jiangsu, China
- Production Capacity：10000 Unit,Units Per Year
Description
ItemGR2205III Basic parameters Engine model QSB6.7 Rated power/speed 164kW/2200rpm Overall dimension (standard) 9300x2625x3470 Total weight (standard) 16500 kg Tire specification 17.5-25 Ground clearance (front axle) 586mm Space of front and rear axles 6447 mm Space of middle and rear wheels 1538 mm Performance
parameters Forward velocity 5,9,12,20,25,45km/h Reverse speed 5,12,25km/h Tractive effort f=0.75 85kN Maximum gradeability 25% Tire inflation pressure 260kPa Working system pressure 22MPa Transmission pressure 1.6-1.8Mpa Working parameters Maximum steering angle of front wheel ±48° Maximum slant angle of front wheel ±17° Maximum oscillating angle of front axle ±15° Maximum oscillating angle of equilibrium box forwards15°, Reverse15° Maximum steering angle of frame ±25° Minimum turning radius 7.3m Scrape knife Maximum lift height 480mm Maximum cutting depth 715mm Maximum tilt angle 90° Cutting angle 29°-69° Angle of revolution 360° Length & chord height 3965x610mm Oil filling amount Coolant 50L Fuel tank 270L Engine 24L Transmission 38L Equilibrium box 60L Drive alex 36L Hydraulic oil 190L
