Mini Excavator Sh20 China Small-Scale Excavator Operating Weight 1.9t
Jinan Sinoheng Import and Export Co., Ltd.- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.045m³
Base Info
- Model NO.：SH20
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Displacement：0.854L
- Rated Power：10kw,2200,R,Min , 11.2 Kw
- Maximum Torque：51.9n.M,1600 R,Min
- Swing Speed：10.5 Rpm
- Bucket Digging Force：13.5kn
- Bucket Arm Digging Force：10.1 Kn
- Theoretical Maximum Traction：17.5 Kn
- Hydraulic Oil Tank Capacity：15.3L
- Engine Fuel Tank Capacity：2.8(1.3)L
- Fuel Tank Capacity：19 L
- Transport Package：Nude Packaging
- Specification：Operating Weight 1880kg
- Trademark：SINOHENG
- Origin：China
- Production Capacity：100PCS,Month
Description
Hydraulic and liquid capacityPump type Plunger pump Working pressure 22 Mpa Flow rate 2x17+14 L/min Hydraulic oil tank capacity 15.3L Engine fuel tank capacity 2.8(1.3)L Fuel tank capacity 19 L
Operating rangeUnit(mm) A Max. Digging radius on ground 3610 mm B Max. Digging radius 3700 mm C Max. Digging depth 2150 mm D Max. Digging height 3275 mm E Max. Dumping height 2310 mm F Max. Vertical digging depth 1740 mm G Min. Rotation radius 1580 mm H Max. Upgrade height of bulldozer blade 275 mm I Max. Digging depth of bulldozer blade 180 mm
Operating range
