• Model NO.：SD16
• Condition：New
• Color：Yellow
• Product Name：SD16 Bulldozer
• Application：Road Construction
• Brand：Shantui
• Rated Power：120,1850kw,Rpm
• Engine：Shangchai Sc11CB184G2b1, Weichai Wd10g178e25
• Dozing Capacity：Straight Tilt Blade 4.5 U Blade 5 Angle Bladem
• Ripper Type：Three-Shank Ripper
• Transport Package：Nude
• Specification：CE, SGS
• Trademark：shantui
• Origin：China
• Production Capacity：200units,Month

Basic Info.

Model NO. SD16 Condition New Color Yellow Product Name SD16 Bulldozer Application Road Construction Brand Shantui Rated Power 120/1850kw/Rpm Engine Shangchai Sc11CB184G2b1/ Weichai Wd10g178e25 Dozing Capacity Straight Tilt Blade 4.5 U Blade 5 Angle Bladem Ripper Type Three-Shank Ripper Transport Package Nude Specification CE, SGS Trademark shantui Origin China Production Capacity 200units/Month

Product Description

Construction machinery supplier Shantui crawler bulldozers / dozers for sale SD16

The SD16 is equipped with a hydraulic drive system with hydraulic control technology and has an advanced structure, providing reliable performance and convenient and flexible operation, making the SD16 an ideal construction machine.

Shantui SD16 Crawler Bulldozers specification :

ITEM	UNIT	SD16
L×W×H (Ripper not included)	mm	5140×3388×3032
Operating weight (Ripper not included)	t	17
Engine	-	Shangchai SC11CB184G2B1/ Weichai WD10G178E25
Rated power	kW/rpm	120/1850
Gradeability	°	30
Blade type	-	Straight tilt blade U blade Angle blade
Blade width	mm	Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040
Dozing capacity	m3	Straight tilt blade 4.5 U blade 5     Angle blade 4.3
Ma× drop below ground of blade	mm	540
Lift height of blade	mm	1095
Ripper type	-	Three-shank ripper
Ripping depth of ripper	mm	572
Lifting height of ripper	mm	592
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	6
Number of track shoes (each side)	-	37
Width of track shoe	mm	510
Track gauge	mm	1880
Ground length and ground pressure	mm/MPa	2430-0.067
Pitch	mm	203.2
Forward speed	km/h	0-3.29
		0-5.82
		0-9.63
Reverse speed	km/h	0-4.28
		0-7.59
		0-12.53
