XCMG 21 Ton Crawler Excavator for Sale
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service:Overseas Service Center Available
- Warranty:1year
- Type:Crawler Excavator
- Usage:Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket:Backhoe
- Transmission:Hydraulic Transmission
Base Info
- Model NO.:Xe210
- Drive Type:Internal Combustion Drive
- Bucket Capacity:>1.5m³
- Size:Large-Scale
- Certification:CE
- Condition:New
- Operation Weight:21140kg
- Rated Power:129,2200kw,Rpm
- Rotating Speed:31r,Min
- Max.Dumping Height:7530mm
- Max.Digging Depth:5755mm
- Tail Swing Radius:2820mm
- Transport Package:Comply with Export Packaging Requirements
- Specification:ISO
- Trademark:XCMG
- Origin:Xuzhou, Jiangsu, China
- HS Code:87059091
- Production Capacity:1000,Year
Description
Overview
Model Unit Parameter Operation weight kg 21140 Bucket capacity m³ 0.86 Engine Model / QSB6.7 Rated power kw/rpm 129/2200 Max.torque N.m 799 Displacement L 6.7 Fuel tank L 305 Main performance Rated flow L/min 220 Working pressure Mpa 32 Hydraulic tank L 202 Rotating speed r/min 13 Bucket digging force kN 115 Arm crowd force kN 91 Min.swing radius mm 6500 Travel speed km/h 9.5/31 Grade ability ° 35° Hydraulic system /Pump/Pilot pump / Tow ram pumps Apperance size AOverall length mm 9135 BOverall width mm 2552 COverall height mm 3370 DGround clearance of counterweight mm 1250 EMin.ground clearance mm 340 FTail swing radius mm 2820 GWheel base of crawler mm 2850 HTumbler distance mm 1890 Iwidth of chassis mm 2495 JDistance bttween the front axle and center rotation mm 1550 KHeight of engine hood mm 2542 LMax.dozer cutting depth mm 145 MMax.dozer lifting height mm 479 (/)Dozer(width/height) mm 2467/566 Working scope AMax.digging radius mm 9613 BMax.ground digging distance mm 9380 CMax.digging height mm 10528 DMax.dumping height mm 7530 EMax.digging depth mm 5755 F8Digging depth at the range of level 8 feets mm 5580 Standard configuration Length of bucket arm mm 2910 Bucket capacity m³ 0.86
Company Profile
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
