Small Cheap Front End Backhoe Loader (WZ30-25)
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Power
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：WZ30-25
- Type：Small Loader
- Shipping Method：40hq Container
- Best Delivery：in 7-10 Days
- Bucket Capacity：1.0m3
- Digger Capacity：0.3m3
- Dumping Clearance：2700mm
- Dumping Reach：950mm
- Engine：Yuchai Diesel Engine
- Dimension：8000 *2200 *3350mm
- Operating Weight：9500kg
- Rated Power：65kw
- Transport Package：Nude
- Specification：ISO9001-2008, GOST
- Trademark：Oriemac
- Origin：Jiangsu, China
- HS Code：84295100
- Production Capacity：4000PCS,Month
Description
Basic Info.
Model NO. WZ30-25 Type Small Loader Shipping Method 40hq Container Best Delivery in 7-10 Days Bucket Capacity 1.0m3 Digger Capacity 0.3m3 Dumping Clearance 2700mm Dumping Reach 950mm Engine Yuchai Diesel Engine Dimension 8000 *2200 *3350mm Operating Weight 9500kg Rated Power 65kw Transport Package Nude Specification ISO9001-2008, GOST Trademark Oriemac Origin Jiangsu, China HS Code 84295100 Production Capacity 4000PCS/MonthProduct Description
Small Cheap Front End backhoe loader (WZ30-25)The WZ30-25 is a new multi-function engineering machine which gathering the loading and excavating in the integral whole machine. It is the new generation model of the development based on the same kind product technical in domestic and international. Having adopted four wheel, hydraulic torque converter, hydraulic steering system, hydraulic. It is extensively used in the road maintenance, farm and developments getting clay for making brickiln, piping builds, the cable builds, park virescence and the excavating of the road opens to dig, broking up, etc. This machine has below characteristics:
| Description | Specifications | Unit |
| Bucket capacity(heaped) | 1.0 | m3 |
| Digger capacity | 0.3 | m3 |
| Dumping clearance | 2700 | mm |
| Dumping reach | 950 | mm |
| Max. steering angle | ±35 | ° |
| Max. steering angle of dig working device | ±85 | ° |
| Tracing speed i(F/R) | 0-6.2 | km/h |
| Tracing speed ii(F/R) | 0-12 | km/h |
| Tracing speed iii(F/R) | 0-20 | km/h |
| Tracing speed iv(F/R) | 0-33 | km/h |
| Back ispeed | 0-8 | km/h |
| Back iispeed | 0-28.5 | km/h |
| Diesel | Yuchai | |
| Model | YC4108 | |
| Modality | ||
| Rated power | 65 | kw |
| Rated speed | 2500 | r/min |
| Wheel base | 2600 | mm |
| Tread | 1700 | mm |
| Tires | 16/70-24 | |
| Max. digging depth | 4400 | mm |
| Max. digging radius | 5471 | mm |
| Overall dimension(L x W x H) | 8000 x 2200 x 3350 | mm |
| Operating weitght | 9500 | kg |
