• Model NO.：LG833n
• Type：Medium-sized Loader
• Bucket Capacity (M3)：1.8
• Rated Payload(Kg)：3500
• Operating Weight(Kg)：11620
• Traction Force(Kn)：106
• Breakout Force(Kn)：103
• Engine：Wp6g140e22 Df Cummins 6bt5.9-C130
• Rated Power(Kw/Rpm)：105,2200 97,2200
• Peak Torque(Nm/Rpm)：580,1400 560,1400-1600
• Tire：17.5-25 L-3 12pr Tt
• Transport Package：Nude Packing
• Specification：2300 X 2105X 1780mm
• Origin：Jiangsu, China
• HS Code：84295100
• Production Capacity：1000,PCS

Overall Data Bucket Capacity (m3)1.8Rated Payload(kg)3500Operating Weight(kg)11620±300Traction Force(kN)106±3Breakout Force(kN)103±3Travel speeds (km/h): IIIIII Forward6.512.032.0 Reverse6.812.533.5 Engine            WP6G140E22 DF CUMMINS 6BT5.9-C130Rated Power(kW/rpm)105/2200                       97/2200Peak Torque(Nm/rpm)580/1400                 560/1400-1600Starting Voltage(V)24Drive Train Torque ConverterSingle-stage, Single-turbine, 3-elementTorque Ratio3.2TransmissionCountershaft Powershift TransmissionGear3F/3RPressure of Transmission(MPa)1.1~1.5Main ReducerSpiral Bevel, 1-stage ReductionFinal ReducerPlanetary ReductionTire17.5-25 L-3 12PR TTBrake System Service BrakeSingle Circuit Caliper,Dry BrakeSetting Pressure (MPa)0.7-0.78Parking BrakeFlexible Shaft Controlled CaliperEmergency BrakeFlexible Shaft Controlled Caliper Steering System TypeHydraulic Load Sensing SystemCylinders-bore×Stroke(mm)2-80×315Steering PumpGear PumpSystem Pressure(MPa)15Flowrate(L/min/rpm)88/2200Steering Angle±35°Hydraulic System Lift Cylinders-bore×Stroke(mm)2-125×784Tilt Cylinder-bore×Stroke(mm)1-140×553Model of Implement PumpGear PumpFlowrate(L/min/rpm)246/2200System Pressure(MPa)16Pilot Control System Pressure (MPa)2.5Hydraulic Cycle Time, Rated Load in Bucket(in second):Raise(Loaded)DumpLower(Empty)Total5.51.33.710.5Electrical SystemSystem Voltage(V)24Battery (2 in series)(Ah)105Lamp Voltage(V)24Service Refill Capacity Fuel Tank(L)200Hydraulic Tank(L)173Crankshaft(L)17Transmission(L)36Front Axle(L) /Rear Axle(L)18.5/18.5Air Conditioning System Heating Capacity(W)5900 (±10%)Cooling Capacity(W)4800 (±10%)
