• Model NO.：L58-C3
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Operating Weight (Kg)：17200
• Transport Package：Roro
• Specification：8100*3030*3540 mm
• Trademark：shantui
• Origin：China
• HS Code：8429510000
• Production Capacity：500,Month

Basic Info.

Model NO. L58-C3 Load and Unload Mode Front Discharge Walking Mode Wheeled Type Medium-sized Loader Operating Weight (Kg) 17200 Transport Package Roro Specification 8100*3030*3540 mm Trademark shantui Origin China HS Code 8429510000 Production Capacity 500/Month

Product Description



SHANTUI Hot Sale High Efficiency Earthmoving Machinery 5 Tons Wheel Loader L58-C3



Product Description



Power System

 Electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts interchangeability, and low maintenance cost.

 The machine is provided with three power modes, namely no-load, medium-load, and heavy-load modes, at choice depending on the actual working load to realize the reasonable match among power, efficiency, and energy consumption.

Driving/Riding Environment

 The new generation  with all-new design optimization and large door structure is mold formed to guarantee broader vision and more fashionable appearance;

The framework structure in four sides enlarges the interior space by >10% to ensure high safety, comfort, and reliability.

 The extensively adjustable seat provides the driver with the most comfortable operation posture.

 The locations of joysticks, pedals, and seat are reasonably arranged to achieve higher operating comfort.

 The standard radio and audio provides more abundant personalized driving/riding experience and guarantees the comfortable and safe driving/riding environment.

Operating performance

 The control of working device features high flexibility, handiness, and comfort and the single and double pilot joysticks are at choice to meet the needs of different customers.

High operating efficiency

 The new bucket in optimized bucket shape is added with overflow plates to improve the bucket fullness rate and shoveling and loading efficiency.

 High tipping load, good heavy-load stability, and high efficiency

Electronic control engine special for Shantui and Shantui's self-made special speed-increasing transmission achieve optimal match performance, good acceleration performance, and fast machine acceleration, and realize high traction force and lifting force, strong burst force, and high operating efficiency under composite working condition (Simultaneous traveling and working motions).

 The double pump confluence working system and load-sensing coaxial flow amplified steering system achieve flexible operations and fast and stable steering speeds. The working pressure is increased to 18MPa and the lifting force is increased by 12% to achieve higher shoveling and loading efficiency.

Convenient maintenances

 The grease extraction pipelines are added and the maintenance locations (Including filter elements) are optimized to ease the daily repairs and maintenances.

Parameter name	L58-C3 SG (Sandstone version)	L58-C3 SG (Coal version)	L58-C3 MH (Ore version)
Performance parameters
Operating weight (Kg)	17200	18000	17650
Maximum dumping height (mm)	3200 (Standard boom)3450 (Extended boom)3700 (Long Boom)	3210 (Extended boom)3420 (Long Boom)	3215 (Standard boom)3260 (Extended boom)
Dumping reach (mm)	1230 (Standard boom)1200 (Extended boom)1270 (Long Boom)	1395 (Extended boom)1510 (Long Boom)	1125 (Standard boom)1310 (Extended boom)
Maximum breakout force (kN)	≥185	≥185	≥185
Total cycle time (s)	10.5	10.5	10.5
Engine
Engine model	WP10	WP10	WP10
Rated power/rated speed (kW/rpm)	162/2000	162/2000	162/2000
Overall dimensions
Overall dimensions of machine (mm)	8100*3030*3540	8460*3050*3540	8160*3075*3540
Driving performance
Forward speed (km/h)	F1:0-13,F2:0-42	F1:0-13,F2:0-42	F1:0-13,F2:0-42
Reversing speed (km/h)	R:0-15	R:0-15	R:0-15
Chassis System
Wheelbase (mm)	3300	3300	3300
Tank capacity
Fuel tank (L)	230	230	230
Working device
Rated bucket capacity (m³)	3	4	2.5
Rated loading capacity (t)	5	5	5
