• Model NO.：XS222J
• Travel Speed：8km,H
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000
• Condition：New
• Transport Package：Nude Package
• Specification：10 ton
• Trademark：EVANGEL
• Origin：China
• Production Capacity：100 Pieces, Month

ItemUnitXS222JOperating weightkg20000Weight on front drumkg10000Static linear loadN/cm516Speed rangekm/h Speed I 2.63Speed II 5.3Speed III 8.6Theoretical gradeability%30Min. external turning radiusmm6500Steering angle°±33Oscillating angle°±10Vibration frequency (high/low)Hz33/28Nominal amplitude (high/low)mm1.86/0.93Excitation force (high/low amplitude)kN374/290Drum diametermm1600Drum widthmm2130Engine model SC8D185G2B1Rated power @2000 r/minkW136Engine oil consumptiong/kW.h223Hydraulic oil tank capacityL170Fuel tank capacityL240
