• Model NO.：YZH5253GJBHW
• Vibrating Amplitude：0.8mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：White
• Weight：16ton
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：LIUGONG
• Origin：Guangxi, China
• Production Capacity：100 Sets,Month

Basic Info.

Model NO. YZH5253GJBHW Vibrating Amplitude 0.8mm Certification ISO9001: 2000, CE Condition New Color White Weight 16ton Transport Package Nude, Suitable for Shiping Specification ISO Trademark LIUGONG Origin Guangxi, China Production Capacity 100 Sets/Month

Product Description

Liugong Hold mini truck concrete mixer YZH5253GJBHW

1. Driving type: 6*4
2. Drum volume: 13.4m3
3. Engine power 247KW China III emission


CHASSIS
Chassis Model DELONG SX5255GJBJR364
Emission Stage CHINA 3
Engine Power 247KW
Engine Displacement 9.726L
Driving Type 6× 4
Wheelbase 3625+1350mm
Max. Running Speed 77km/h
Min. Turning Radius 19 m
Brake type Air pressure of double loop
Truck loading capacity 12070 kgs


DRUM
Drum material Baosteel B520JJ
Drum volume 13.4 m³
Drum loading capacity 8 m³
Drum agitating volume 5 m³
Material charge speed ≥ 3 m³ /min
Material discharge speed ≥ 2.7 m³ /min
Material discharge control Manual
Drum remnant ratio of discharging ≤ 0.5%
Drum rotating speed 0-18 (r/min)
Drum tilt angle 13°


HYDRAULIC SYSTEM
Hydraulic pump Sauer KPV23-674R
Hydraulic pump type Piston pump
Hydraulic motor Sauer KMF23-516-50
Speed reducer Sauer TMG61.2
Hydraulic circuit type closed circuit cycle
Hydraulic tank capacity 20L
Water tank capacity 450 L

DIMENSIONS&WEIGHT
Overall Length 8850mm
Overall Width 2496 mm
Overall Height 3780 mm
Truck gross Weight 25000 kgs
Truck net weight 12800 kgs
DIMENSIONS&WEIGHT
Overall Length 8850mm
Overall Width 2496 mm
Overall Height 3780 mm
Truck gross Weight 25000 kgs
Truck net weight 12800 kgs
