| Complete machine parameters |
| Rated load(kg) | 5000 |
| Operating mass (standard)(kg) | 16600 |
| Bucket capacity(m3) | 2.8 |
| Boom lifting time(S) | 5.57 |
| Sum of three items(S) | 10.2 |
| Max. traction force(kN) | ≥160 |
| Max. breakout force(kN) | ≥175 |
| Running system |
| Forward speed range(km/h) | 42 |
| Backward speed range(km/h) | 17.5 |
| Gearbox shift | Front : 2 gears rear: 1gears |
| Max. gradeability | 30° |
| Steering angle | 37°+-1° |
| Tire model | 23.5-25 |
| Service brake | Single circuit, air-over-oil four-wheel caliper disc brake |
| Parking brake | flexible shaft control caliper disc brake |
| Tire center(mm) | 5665 |
| Outside of bucket(mm) | 6850 |
| Hydraulic system |
| Working system pressure(Mpa) | 18 |
| Working system displacement(ml/r) | 100 |
| Steering system pressure(Mpa) | 16 |
| Steering system displacement(ml/r) | 80 |
| Hydraulic oil volume(L) | 210 |
| Working scope |
| Outline dimension(mm) | 7700×2980×3430 |
| Wheelbase(mm) | 2920 |
| Track(mm) | 2250 |
| Min. grounding distance (at hinge position)(mm) | 480 |
| Max. unloading height(mm) | 3135 |
| Unloading distance at max. unloading height(mm) | 1195 |
| Engine parameters |
| Model(Weichai) | Weichai WD10G220E23 |
| Type (Weichai) | Six-cylinder, in-line, direct injection, turbocharging, and water cooling |
| Rated power(Kw/rpm)(Weichai) | 162/2200 |
| Max. torque / speed(N.m/rpm)(Weichai) | 890 |
| Cylinder bore x stroke(mm)(Weichai) | Φ126Χ130 |
| Displacement(L) | 9.726 |
| Fuel consumption rate at rated working condition(g/Kw.h) | 210.5 |
| Fuel tank capacityt(L) | 280 |
