• Model NO.：DGL5310TFC-T424
• Certification：ISO9001: 2000, CE
• Condition：New
• Transport Package：in Nude
• Specification：9800*2500*3600mm
• Trademark：DAGANG
• Origin：China
• Production Capacity：5000PCS,Year

Model

Euro IV

DGL5250TFC-T384

DGL5310TFC-T424

DGL5250TFC-T454

Euro III

DGL5251TFC

DGL5311TFC

/

Configuration

Economical

Standard

Standard

Standard

Displacement and Power of Engine(ml/kW)

9726/221

9726/221

9726/247

11596/247

Total Mass( kg )

25000

25000

31000

24870

Aggregate Size(mm)

3-25

3-25

3-25

3-25

Sealing Width(mm)

3800

3800

4200

4500

Working Speed(km/h)

3-6

3-6

3-6

3-6

Asphalt Spraying Rate

(kg/m²)

0.5-3

0.5-3

0.5-3

0.5-3

Chip Spreading Rate

(L/m²)

2-22

2-22

2-22

2-22

Asphalt Tank(L)

6000

6000

8000

10000

Aggregate Bin(m³)

10

10

13.5

13.5

Overall Dimensions(L×W×H)(mm)

Euro IV

9880×2500×3785

9880×2500×3785

10900×2500×3785

11600×2500×3750

Euro III

9880×2500×3750

9880×2500×3750

10900×2500×3750

/
