8t 10t 12t High End Fully Hydraulic Double Drum Vibratory Road Roller
Henan Haiheng Import and Export Co., Ltd.- Type:Road Roller
- Working Method:Vibration
- Axle:Biaxial Dual-Drum
- Grinding Wheel Type:Light Grind
- Compaction Depth:35cm
- Engine Type:Diesel Engine
Base Info
- Travel Speed:35cm,s
- Centrifugal Force:27KN
- Certification:CE, RoHS, ISO 9001:2008
- Condition:New
- Operating Mass:8000kg
- Static Linear Load:210n,Cm
- Overall Dimensions:5080×2160×2850 mm
- Vibration Frequency:40,50Hz
- Warranty:One Year or 1500 Working Hours
- Max. Travel Speed:12km,H
- Drum Diameter:1150 mm
- Turning Radius:7000 mm
- Wheelbase:3340 mm
- Diesel Power:93 Kw
- Transport Package:Container, RO - RO Ship, Frame Cabinet, etc.
- Specification:CE, Rohs, ISO9001, ISO4001
- Trademark:CHHGC
- Origin:Henan, China
- HS Code:84294
- Production Capacity:5000 Sets,Year
Description
Basic Info.
Travel Speed 35cm/s Centrifugal Force 27KN Certification CE, RoHS, ISO 9001:2008 Condition New Operating Mass 8000kg Static Linear Load 210n/Cm Overall Dimensions 5080×2160×2850 mm Vibration Frequency 40/50Hz Warranty One Year or 1500 Working Hours Max. Travel Speed 12km/H Drum Diameter 1150 mm Turning Radius 7000 mm Wheelbase 3340 mm Diesel Power 93 Kw Transport Package Container, RO - RO Ship, Frame Cabinet, etc. Specification CE, Rohs, ISO9001, ISO4001 Trademark CHHGC Origin Henan, China HS Code 84294 Production Capacity 5000 Sets/YearProduct Description
High End Fully Hydraulic Double drum Vibratory Road Roller For SaleHighlights Specifications:
This type is our high-end model. Full hydraulic wheel drive, continuously variable transmission, wheel vibration, frequency amplitude, US 4BT3.9 Cummins diesel engine, walking system and vibration system adopts imported SAUER piston pumps, motors, front and rear electric sprinkler comes standard with rotating cab seats....Most Center Parts Are Imported.
Main technical parameters:
Items | Unit | Model: HDD212H | Model: HDD210H | Model: HDD208H |
0perating mass | kg | 12000 | 10000 | 8000 |
static linear load | N/cm | 282 | 235 | 210 |
Vibration amplitude | mm | 0.74/0.35 | 0.74/0.35 | 0.67/0.35 |
Vibration frequency | Hz | 40/50 | 40/50 | 40/50 |
Centrifugal force | kN | 150×2/99×2 | 115×2/85×2 | 90×2/69×2 |
Max. travel speed | km/h | 13 | 13 | 12 |
Gradeability | % | 40 | 40 | 40 |
Turning radius | mm | 7000 | 7000 | 7000 |
Drum width | mm | 2130 | 2130 | 1870 |
Drum diameter | mm | 1350 | 1250 | 1150 |
Wheelbase | mm | 3440 | 3368 | 3340 |
Ground clearance | mm | 350 | 320 | 300 |
Diesel model | Cummins4BTA3.9 | Cummins4BTA3.9 | Cummins4BTA3.9 | |
Diesel power | kW | 93 | 93 | 93 |
Overall dimensions | mm | 5360×2270×2970 | 5080×2270×2920 | 5080×2160×2850 |
Main Features:
1.Imported COMMINS 4BTA3.9 water cooled diesel engine with rich power surplus.
2.Hydrostatic all-drum travel drive by imported hydraulic motors at two range infinitely variable speeds.
3.Dual frequency and amplitudes vibration system with imported piston pump and motors.
4.Center articulated steering with crabwalk unit for flexible maneuverability.
5.Integrated multi-disc wet brake with oil-cutoff braking for reliable safety.
6.Beautiful streamline shape appearance and front mounted operator's platform for excellence sight.
7.Comfortable and spacious operator's cab with dual steering wheels and seats for convenient operations.
8.Electric power sprinkler system with large capacity reinforced polyethylene water tank.
Aplications of hydraulic double drum vibratory road roller
Hydraulic double drum vibratory rollers are manufactured according to international advanced technology and by use of imported main components abroad, suitable for compaction of various stabilized soils, bituminous concrete and rolling cement concrete (RCC) on road surface construction, also for compaction of road base course,which are universal compaction equipments for high-class highway, airport, harbors, dams, municipal road and industrial ground.
