• Model NO.：ZL10
• Type：Small Loader
• Rate Load (Kg)：1000
• Bucket Capacity (M3)：0.6
• Min. Turning Radius (mm)：3000
• Engine Model：Xinchai 490(Euro III)
• Maximum Lifting Height：4100
• Max. Breakout Force (Kn)：30
• Drive Means：Four Wheel Drive
• Operating Weight (Kg)：3000
• Overall Dimensions (Length*Width*Height)：5900*1700*2650
• Engine Rated Power (Kw)：36.8
• Transport Package：Nude Packing
• Specification：CE
• Trademark：Kudat
• Origin：China
• HS Code：8429
• Production Capacity：500units,Month

Specificationoverall weight(kg)3000L×W×H(mm)5900×1700×2650rated bucket capacity(m3)0.6Rated load(kg)1000Maximum Lifting height (mm)4100Bucket indicatorYesMax. breakout force(KN)30EngineModelXinchai 490(EURO III)TypeIn-line arrangement,
Water cooling, four-strokeRated power(kw)36.8kwRated speed(r/min)2400Transmission systemModel of torque converterYJ240Typesingle-phase single-stage
radial-inward turbine triplexGearbox typeFixed-spindle power shiftGear shift2 gears ahead,2 gear asternHydraulic systemDistribution of work valveZL20BWorking pumpCBGj1032,CBGq1018Steering systemTypeArticulated hydraulic steeringMax. turning angle27±1°Min turning radius(mm)3000Brake systemBrake typeOil brake(Vacuum booster)TyresStandard tyres12-16.5Optional wide tyres14-17.5
