High Quality 800t/H Asphalt Concrete Paver RP903 for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Warranty：Provided
- Type：Asphalt Concrete Paver
- Object：Asphalt Concrete Pavement
- Moving Type：Mobile
- Mixing Method：Continuous Drum
Base Info
- Model NO.：RP903
- Automatic Grade：Automatic
- Product Capacity：600t,H
- Certification：CE
- Condition：New
- Engine Power：159kw
- L*W*H：7290*3000*3950mm
- Maximum Travel Speed：2.8km,H
- Basic Pave Width：9m
- Vibration Frequency：0-40Hz
- Transport Package：Nude
- Specification：27500kg
- Trademark：SINOMADA
- Origin：China
- HS Code：8426411000
- Production Capacity：100units,Month
Description
Product Parameters
project
unit
Performance parameter
Basic paving width
m
3
Maximum paving width
m
9
Maximum paving thickness
mm
300
Speed of work
m/min
0~18
Driving speed
km/h
0~2.8
Theoretical productivity
t/h
800
Hopper capacity
t
15
Gradeability
%
20
Flatness (standard deviation)
mm
≤1.2
Cross slope error
%
±0.02
Crown adjustment range
%
-1~+4
Diesel engine model
BF6M1013
Diesel engine power
kW
159
Diesel engine speed
r/min
2000
Heating generator power
kW
28
Total Weight
t
24.3~27.5
Dimensions
mm
7290×3000×3950
Splitting speed
r/min
0~84
Conveying speed
m/min
0~22
Vibration speed
r/min
0~1800
Vibration amplitude
mm
4
Vibration frequency
Hz
0~40
Screed heating method
/
Electric heating
Conveying material level control mode
/
Ultrasonic sensor automatic control
Vibration form
/
Eccentric vibration
Automatic leveling control mode
/
MOBA digital corner leveling instrument
