Strong Structure 24 Ton Crawler Bulldozer SD22W Rock Version
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Warranty：Provided
- Type：Special Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：SD22W
- Engine Power：175kw
- Certification：CE
- Condition：New
- Color：Yellow
- L*W*H：5495*3725*3402mm
- Ground Pressure：66kpa
- Track Shoe Width：560mm
- Transport Package：Nude
- Specification：23600kg
- Trademark：SINOMADA
- Origin：China
- HS Code：8426411000
- Production Capacity：100units,Month
Description
Overview
Hot Products
Product Description
Product Description- Product Parameters
Number name
SD22W (rock version)
Performance parameter
Work mass (kg)
23600
Ground pressure (kPa)
66
engine
engine model
QSNT-C235
Rated power/rated speed (kW/rpm)
175/1800
Dimensions
Overall dimensions (mm)
5495*3725*3402
Walking performance
Forward speed (km/h)
F1:0-3.6 F2:0-6.5 F3:0-11.2
Backward speed (km/h)
R1:0-4.3 R2:0-7.7 R3:0-13.2
Chassis system
Track center distance (mm)
2000
Track shoe width (mm)
560/610/660
Grounding length (mm)
2730
Fuel tank capacity
Fuel tank (L)
450
working equipment
Blade type
Rock straight-dip shovel, rock angle shovel, rock U-shaped shovel, rock half-U shovel
Dozer blade capacity (m³)
4.6, 3.4, 6.7, 5.8
Shovel depth (mm)
540
Ripper type
Single tooth three teeth
Loose soil depth (mm)
Single 695 Three 666
