Mechanical Brake 10.8ton Motor Grader Sg14-3c for Construction
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Warranty：Provided
- Certification：CE
- Condition：New
- Application：Railway, Mine, Farmland, Highway
- Transmission：Hydraulic
Base Info
- Model NO.：SG14-3C
- Walking Mode：Wheeled
- Type：Medium-sized Grader
- Engine Power：105kw
- L*W*H：7921*2380*3170mm
- Max Forward Speed：44km,H
- System Pressure：16 MPa
- Transport Package：Nude
- Specification：10870kg
- Trademark：SINOMADA
- Origin：China
- HS Code：8426411000
- Production Capacity：100units,Month
Description
Product Parameters
Comparison item
SG14-3C
Performance parameter
Working quality of the whole machine (kg)
10870
Wheelbase (mm)
5813
Wheel base (mm)
2050
Minimum ground clearance (mm)
430
Front wheel steering angle (°)
±45
Articulated steering angle (°)
±25
Maximum traction force (kN)
64
Turning radius (mm)
6600 (outside of front wheel)
Maximum climbing ability (°)
20
Blade width (mm)
3660
Blade height (mm)
615
Swivel angle of blade (°)
360
Blade cutting angle (°)
30-68
Maximum cutting depth of blade (mm)
500
Length (mm)
7921
Width (mm)
2380
Height (mm)
3170
engine
engine model
WP6G140E22
emission
Kunji
form
In-line, water-cooled, four-stroke, turbocharged
Rated power/rated speed (kw/rpm)
105/2200
Transmission system
Torque converter
Single-stage single-phase three-element
Gearbox
Fixed axis power shift
Gear
First six and last three
Forward gear speed (km/h)
5.4
Forward gear speed (km/h)
8.3
Forward gear speed (km/h)
13.2
Forward IV gear speed (km/h)
20.6
Forward V gear speed (km/h)
29.6
Forward VI gear speed (km/h)
44
Reverse gear speed (km/h)
5.4
Backward speed of second gear (km/h)
13.2
Backward speed of third gear (km/h)
29.6
Braking System
Service brake type
Hydraulic brake
Parking brake type
Mechanical brake
Brake oil pressure (MPa)
10
Hydraulic system
Working pump
Quantitative gear pump, displacement 25ml/r
Working valve
Integral multi-way valve
Set pressure of safety valve (MPa)
16
Steering Pump
Quantitative gear pump, displacement 25ml/r
Set pressure of safety valve (MPa)
12.5
Oil filling
Fuel tank (L)
220
Working hydraulic oil tank (L)
85
Engine (L)
13.3
Gearbox (L)
28
Drive axle (L)
25
Balance box (L)
2X23
