China 20 Tons Horizontal Directional Drill Xz200 for Hot Sale
Maxizm Construction Machinery (Qingdao) Co., Ltd.- Type：Drill
- Pressure Pile Driver Type：Hydraulic Pile Driver
- Pile Hammer Type：Hydraulic Hammer
- Power Source：Diesel
- Motor Power：112kw
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
Base Info
- Model NO.：XZ200
- Condition：New
- Engine Model：6btaa5.9-C150
- Spindle Speed：0-155r,Min
- Max.Mud Flow Rate：200,250L,Min
- Max.Mud Pressure：80bar
- Transport Package：Nude Package
- Specification：6200*2250*2400mm
- Origin：Jiangsu China
- HS Code：8430691900
- Production Capacity：1000units,Month
Description
Basic Info.
Model NO. XZ200 Condition New Engine Model 6btaa5.9-C150 Spindle Speed 0-155r/Min Max.Mud Flow Rate 200/250L/Min Max.Mud Pressure 80bar Transport Package Nude Package Specification 6200*2250*2400mm Origin Jiangsu China HS Code 8430691900 Production Capacity 1000units/MonthProduct Description
XZ200 China Manufacturer 20 tons Horizontal Drilling Machine
Feature:
(97KW) engine, 180kN of push-pull, 6000N.m of Max.spindle torque, motor dual speed chain push-pull system, self-propelled rubber tracks chassis, automatic loading and unloading drill rod device, rotatable control board, patent technology for floating vice, and onboard high-capacity mud pump (250L/min).
| Main Technical Specification | |
| Model | XZ200 |
| Engine | CUMMINS |
| Rated power | 112 |
| Push-pull | Rack and pinion |
| Max.pullback/thmsting | 200/200 |
| Spindle torque (max) | 6350 |
| Spindle speed | 0-160 |
| Travelling speed of power head | 0-26 |
| Backreaming diameter | Φ600 |
| Pipe length(single) | 3 |
| Pipe diameter | Φ60 |
| Entry angle | 10~22 |
| Mud flow rate (max) | 200/250 |
| Mud pressure (max) | 80 |
| Overall weight | 8.5 |
| Dimension (LxWxH) | 5900x2250x2400 |
