Catapillar D9 Dozer for Sale
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
- Engine Power：147~515kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：D9
- Condition：New
- Color：Yellow
- Transport Package：Nude
- Specification：6215*3416*3120mm
- Trademark：CATERPILLAR
- Origin：China
- HS Code：8429510000
- Production Capacity：5000PCS,Year
Description
Basic Info.
Model NO. D9 Condition New Color Yellow Transport Package Nude Specification 6215*3416*3120mm Trademark CATERPILLAR Origin China HS Code 8429510000 Production Capacity 5000PCS/YearProduct Description
catapillar D9 dozer for saleProduct Description
1. The TY160 bulldozer which has excellent power, reliability and a long service life. Through the introduction of Japanese D65A-8 bulldozer technology, at the same time absorb the advantages of D60A-8,The TY160 crawler type bulldozer has been developed by the domestic design.
2. the WP10G178E25 type engine, fuel strainer to remove water filter, fuel filter assembly is a rotary type fuel filter assembly, air filter for air filter with turbo type pre filter assembly. The power is strong, the performance is reliable, and the after-sales service is convenient.
3. control console and isolation buffer material can reduce noise and reduce vibration and make the operation more comfortable.
| Engine Model | Cat® C18 ACERT™ |
| Flywheel Power | 306 kW |
| Bore | 145 mm |
| Stroke | 183 mm |
| Displacement | 18.1 l |
| Engine Power - ISO 14396 | 329 kW |
| Engine Power - Net SAE J1349/ISO 9249 | 306 kW |
| Net SAE J1349/ISO 9249 | 306 kW |
| Emissions | U.S. EPA Tier 2/EU Stage II Equivalent and U.S. EPA Tier 3/EU Stage IIIA Equivalent |
| Engine Power - Gross SAE J1995* | 334 kW |
| Note (1) | * Excludes all fan losses. |
| Note (3) | Net power advertised is the power available at the flywheel when the engine is equipped with fan at max speed, air cleaner, muffler and alternator. |
| Note (2) | Engine ratings apply at 1,833 rpm. |
| Note (4) | No derating required up to 2286 m (7,500 ft) altitude. High altitude attachment available for greater than 2286 m (7,500 ft). |
| Operating Weight | 47872 kg |
| Shipping Weight | 35746 kg |
| Note (1) | Operating Weight: Includes hydraulic controls, blade tilt cylinder, coolant, lubricants, full fuel tank, ROPS, FOPS cab, SU-Blade, Single-Shank Ripper, 610 mm (24 in) ES shoes, and operator. |
| Note (2) | Shipping Weight: Base machine chassis with cab, pivot shaft, roller frames, track and ROPS. |
| Pump Type | Piston-type pump geared from flywheel |
| Pump Output - Steering | 387 l/min |
| Pump Output - Implement | 226 l/min |
| Tilt Cylinder Flow - Rod End Flow | 140 l/min |
| Tilt Cylinder Flow - Head End Flow | 188 l/min |
| Bulldozer Relief Valve Setting | 26200 kPa |
| Tilt Cylinder Relief Valve Setting | 19300 kPa |
| Ripper - Lift - Relief Valve Setting | 26200 kPa |
| Ripper - Pitch - Relief Valve Setting | 26200 kPa |
| Steering | 40500 kPa |
| Tank Capacity | 89 l |
