• Model NO.：Clg621
• Travel Speed：40cm,s
• Centrifugal Force：30.5KN
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Color：Yellow
• Static Linear Pressure：496n,Cm
• Dimension(L*W*H)：6140*2320*3110 mm
• Wheel Base：3100 mm
• Operating Weight：21000 Kg
• Engine Model：Shangchai Sc5d130g2b1
• Min. Ground Clearance：520 mm
• Power(W)：92 Kw
• Frequency：30
• Warranty：1 Year or 2000 Working Hours
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：Liugong
• Origin：Guangxi, China
• Production Capacity：100 Sets,Month

MassOperating Mass(kg)21000Mini. Operating Mass(kg)18000Mass on Steering Drum(kg)7560Mass on Driving Drum(kg)13440Front Drum Static Linear Load (N/cm)496Vibration Frequency(Hz)Nominal Amplitude(mm)CompactionCentrifugal Force(kN)Drum Diameter(mm)1320Drum Width(mm)1600Drum Thickness(mm)650Steering Drum Thickness(mm)27.5Driving Drum Thickness(mm)37Drive1st Maximum Speed,fwd(km/h)2.52nd Maximum Speed,fwd(km/h)53rd Maximum Speed,fwd(km/h)10.5Theoretical Gradeability(%)20Min. Ground Clearance(mm)520Wheelbase(mm)3100Steering Angle(°)±35Swing angle(°)10Min. Outside Turning Radius(mm)6500Tyre TypeOverall Length(mm)6140Overall Width(mm)2320Overall Height(mm)3110EngineBrandShangchaiModelSC4H125.2G3Emission RegulationTier IIIRated Power(kW)92Rated Rotation Speed(r/min)1800Theoretical Fuel Consumption(g/kW.h)217.7Torque(N.m)550Number of Cylinders4Displacement(L)4.3AspirationTurbochargedCooling TypeWaterDrive AxleBrandLiugongModel50CVolumeBattery(V/Ah)24/200Alternator(V/A)28/55Rear Axle(L)24Wheel Reduction Gear(L)6×2Fuel Tank(L)280Hydraulic Oil Tank(L)38Engine Oil(L)14Transimission/Torque Converter(L)14.5Coolant(L)15Water Tank(L)200Weight on Front Axle(T)Weight on Rear AxleFile and CertificateIntroduce Document of ProductsParts ManualMaintenance Manual√Service ManualCE CertificateGOST CertificateROPS CertificateType-test Certificate
