High Pressure Cast Iron Gear Pump Hydraulic Pump Cbztg2

HEFEI CHANGYUAN HYDRAULIC CO., LTD.

Application：Forklift, Loader, Grader, Crane, Mining Machinery
Certification：ISO9001:2008
Condition：New
Material：Casting Iron
Product Name：Hydraulic Gear Pump
Nominal Displacement：63~100ml,R

Base Info

Model NO.：CBZTG2
Rated Pressure：200 Bar
Max. Pressure：250 Bar
Min. Speed：600 R,Min
Rated Speed：2000 R,Min
Max. Speed：2500 R,Min
Volumetric Effciency：90%
Customized Service：Ok
Transport Package：Packed in Export Standard
Specification：9kg
Trademark：Heye & HCHC
Origin：Anhui, China
Production Capacity：6000 PCS,Month

Description

90

25.3CBZTG2090-BFΦ*9024.3CBZTG2080-BFΦ*8023.7CBZTG2070-BFΦ*7022.8CBZTG2063-BFΦ*6322.1 High Pressure Cast Iron Gear Pump Hydraulic Pump Cbztg2
