• Model NO.：FR330D
• Size：Medium-Sized
• Certification：ISO9001: 2000
• Condition：New
• Engine：Isuzu Engine
• Maximum Dig Depth：3925mm
• Main Value：Kawasaki Main Value
• Transport Package：Nude Packing
• Trademark：LOVOL
• Origin：China
• Production Capacity：100 Units,Month

Main ParametersOperation Weight (Standard Configuration) (KN)33600Standard Bucket Capacity(m³)1.4-1.6Transport Dimensions(mm)11303*3202*3290Bucket Digging Force (KN)205Maximum Traction Force (KN)290DeviceMax. Travel Speed (Km/h)5.5/3.3Climbing Gradeability(°)35Total Length of the Crawler (mm)4600Minimum Revolving Radius (mm)4320Width of the Crawler (mm)600Ground Pressure (Kpa)68Turning Speed (rpm)10EngineModelISU-ZU AA-6HK1XQPTypeFour Strokes, Water-cooling, Straight, Turbocharger, Inter CoolingRated Power (kW/rpm)190.5/2000Rated Torque (N.m/rpm)872.8/1700Cylinder Diameter*Stroke (mm)115*125Output Value (L)7.79Fuel Consumption (g/KW.h)237Fuel Tank Capacity (L)630Hydraulic SystemMain Pump Pressure (Mpa)34.3/37.3Main Pump Flow (L/min)311*2Operating ScopeMaximum Digging Height (mm)10210Maximum Unloading Height (mm)7140Maximum Digging Depth (mm)7380Maximum Digging Radius (mm)11100
