• Model NO.：ZLM15B
• Type：Small Loader
• Brand Name：Changlin
• Model Number：Zlm15b
• Bucket Capacity：10cbm
• Load and Unload Method：Front Discharge
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：FOTON LOVOL
• Origin：China(Mainland), Shandong
• Production Capacity：1500 Units, Year

Length(with bucket on ground)
 Length(with bucket on ground)
 5710(mm)
   Width(to outside of wheels)
 2010(mm)
   Bucket width
 2070(mm)
   Height(To the top of the cab)
 2975(mm)
   Wheel base
 2300(mm)
   Tread
 1600(mm)
   Min. ground clearance
 342(mm)
   Main Technical Specification
 Rated load
 1800(Kg)
   Operating weight
 6550KG
   Rated bucket capacity
 1.0(m3)
   Max. breakout force
 57kN
   Max. dump clearance
 2520(mm)
   Dump reach
 960(mm)
   Dump angle at any position
 ≥450
   Digging depth(with bucket bottom horizontal)
 146(mm)
   Max. turning radius
   (1) Outside of bucket
 4850(mm)
   (2) Center of rear wheel
 4420(mm)
   Pivot angle frame
 38+1 0
   Oscillating angle of rear axle
 +11 0
   Lifting time of bucket
 ≤5(sec.)
   Lowering time of bucket
 ≤3.2(sec.)
   Dumping time
 ≤2 (sec.)
   Traveling speed(Km/h),2 forward and 2 reverse
  (1) 1st gear forward
 5.75
   (2) 2nd gear forward
 23.86
   (3) 1st gear reverse
 5.85
   (4) 2nd gear reverse
 24
   Diesel engine
 Model
 Cummins 4BT3.3-C80 (made in Japan)
   Type
 Direct injection. Turbocharged. Water cooling
   Rated output
 60 (kW)
   Inter-bore of cylinder/stroke
 95 /115(mm)
   Total exhaust of cylinder
 3.3(L)
   Voltage of starting motor
 12/24 (V)
   Rated speed
 2200(r/min)
   Max. Torque
 259(N.M)
   Starting type
 Electric
   Min. specific fuel consumption
 225(g/Kw.h)
   Net weight
 255(kg)
