High Quality Lower Price 3 Ton Wheel Loader (ZL30G) for Sale
Evangel Industrial (Shanghai) Co., Ltd.- Certification：ISO, RoHS, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：ZL30G
- Type：Medium-sized Loader
- Bucket Capacity：1.7m3
- Dumping Clearnce：2800mm
- Dumping Reach：1030mm
- Ling Timet<10ts Max.Traction Force：90kn
- Transport Package：Suitable Package for Shipment
- Specification：CE
- Trademark：China
- Origin：Jiangsu, China
- Production Capacity：30 Sets Per Month
Description
ZL30G wheel loader main specificationDescription Specification Unit Bucket capacity 1.7 m 3 Rated load 3000 kg Dumping clearnce 2800 mm Dumping reach 1030 mm Raising time <6 s Total cycling time <10 s Max.traction force 90 kN Max.breakout force 110 kN Articulation angle 40±1 ° Min.turning radius <4800 mm Gradability 28 ° Wheel base 2700 mm Track 1850 mm Travel speed , , 1st(F/R) 7.8/9.5 km/h 2nd(F/R) 13/28 km/h 3rd(F) 25 km/h 4th(F) 35 km/h
, , Engine model YC6105G-1640H , Rated power/rated speed 85kw/2300r/min , LXWXH 6830×2460×3170 mm Operating weight 10.5 t Tyres 17.5-25
3ton Wheel Loader (ZL30G) 1.8cbm capacity
1. Optimum design of working device, dumping clearance, dumping reach, breakout force, raising capacity, short total cycling time, automatic leveling at high position, and greater productivity.
2. Center-point frame articulated, small turning radius and front and rear wheels track reduce resistance and tyre wear and improve the going-through capability of the whole machine.
3. Fully hydraulic steering, power shift transmission, flexible operation.
4. Key-block type propeller shaft, resistance against strike is strong, Power transmitting is reliable.
5. Air-valve control band type emergency brake system, safety and reliability.
6. Integrated hood made of compound material, right and left open, auto-lock, reduce sound. Operation and maintenance easy.
7. The design of luxury cab ergonomically, excellent sight. Operational air conditioner provides operator with a comfortable job environment.
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
3ton Wheel Loader (ZL30G) 1.8cbm capacity
1. Optimum design of working device, dumping clearance, dumping reach, breakout force, raising capacity, short total cycling time, automatic leveling at high position, and greater productivity.
2. Center-point frame articulated, small turning radius and front and rear wheels track reduce resistance and tyre wear and improve the going-through capability of the whole machine.
3. Fully hydraulic steering, power shift transmission, flexible operation.
4. Key-block type propeller shaft, resistance against strike is strong, Power transmitting is reliable.
5. Air-valve control band type emergency brake system, safety and reliability.
6. Integrated hood made of compound material, right and left open, auto-lock, reduce sound. Operation and maintenance easy.
7. The design of luxury cab ergonomically, excellent sight. Operational air conditioner provides operator with a comfortable job environment.
The imported engine with original packing has strong power, and can meet the requirements of high-efficient work.
- Precise matching design with advanced energy conservation control can reduce the oil consumption of the machine.
- Low emission meets the Europe II standard.
- The adoption of new cooling fan and large-scale silencer lowers the noise of the machine.
- The adoption of the advanced turbocharging technique increases the highland adaptability of the machine.
- Automatic preheating system improves the working capacity in the low temperature.
- Unique fan cover with the shape of hopper opening greatly improves the air supply of the engine and the radiating capacity of the system, guaranteeing the successive high-efficient work of the machine.
- Restart prevention system effectively avoids the misoperation, and improve the use security of the machine.
