Shantui Heavy Duty Excavator Se245LC with 1.2cbm Bucket Capacity
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE245LC
- Drive Type：Electric Drive
- Bucket Capacity：1.2cbm
- Size：Large-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Minimum Ground Clearance (mm)：465
- Tail Turning Radius (mm)：3000
- Track Length (mm)：4660
- Track Gauge (mm)：2580
- Track Width (mm)：3180
- Standard Track Shoe Width (mm)：600
- Turntable Width (mm)：2725
- Maximum Digging Height (mm)：10180
- Maximum Dumping Height (mm)：7200
- Maximum Digging Depth (mm)：6864
- Maximum Vertical Digging Depth (mm)：5978
- Maximum Digging Distance (mm)：10198
- Engine Model：Qsb7(China III)
- Rated Power (Kw/Rpm)：150,2050
- Rated Working Flow (L/Min)：2*238
- Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification：9985*3235*3180mm
- Trademark：shantui
- Origin：China
- Production Capacity：300piece,Month
Description
Basic Info.
Model NO. SE245LC Drive Type Electric Drive Bucket Capacity 1.2cbm Size Large-Scale Certification CE, ISO9001: 2000 Condition New Minimum Ground Clearance (mm) 465 Tail Turning Radius (mm) 3000 Track Length (mm) 4660 Track Gauge (mm) 2580 Track Width (mm) 3180 Standard Track Shoe Width (mm) 600 Turntable Width (mm) 2725 Maximum Digging Height (mm) 10180 Maximum Dumping Height (mm) 7200 Maximum Digging Depth (mm) 6864 Maximum Vertical Digging Depth (mm) 5978 Maximum Digging Distance (mm) 10198 Engine Model Qsb7(China III) Rated Power (Kw/Rpm) 150/2050 Rated Working Flow (L/Min) 2*238 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 9985*3235*3180mm Trademark shantui Origin China Production Capacity 300piece/MonthProduct Description
Shantui Heavy Duty Excavator SE245LC With 1.2Cbm Bucket Capacity__________________________________________________________________________________
CHARACTERISTICOptional attachments
Breaking hammer, ripper, timber grab, stone grab, hydraulic tamper, quick change coupling, and breaking hammer pipeline.
Optional equipment of machineRefueling pump
Cab warning lamp
Cab ceiling lamp
Cab overhead protective net
Cab front upper protective net
Cab front lower protective net
Rubber track
Narrow bucket
Spacious and comfortable operating environmentThe colors of the all-injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.
The control devices are reasonably arranged to realize large space, broad vision, and convenient and comfortable operations.
The high-power A/C system and the air cushioned seat guarantee comfortable driving/riding.
Quick and convenient maintenancesSupported by two cylinders, the backward-opening engine hood features handy opening, large opening angle, and easy maintenances.
The electric parts are centrally arranged to ease the checking and maintenances.
The filling of coolant, the replacement of air filter element, and the power master switch are easily accessible.
The parallel radiator effectively avoids the overheating and eases the cleaning.
The fuel filter element, engine oil filter element, and pilot filter element are centrally arranged so that all maintenances and replacements can be completed from on same position
The high-precision fuel filter element features powerful fuel adaptability and the electric fuel pumping function is provided for automatic fuel refilling and easy start.
Intelligent electronic control and optimal power controlThe intelligent control system realizes the optimal match between power system and hydraulic system to improve the working efficiency. The automatic idling function is provided to lower the fuel consumption and reduce the operating cost.
The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Drive sprockets, idlers, track rollers, carrier rollers, and tracksDecades of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and world's leading technologies
The world's sophisticated forging and heat treatment processes guarantee stable and reliable quality.
Enhanced working deviceThe design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
High-end system configurationDomestic leading high-adaptability engine.
The world's first-class hydraulic configuration features high working pressure and low pressure loss.
PARAMETER| Comparative item | SE245LC (Standard version) |
| Overall dimensions | |
| Overall length (mm) | 9985 |
| Ground length (During transport) (mm) | 5350 |
| Overall height (To the top of boom) (mm) | 3235 |
| Overall width (mm) | 3180 |
| Overall height (To top of cab) (mm) | 3075 |
| Ground clearance of counterweight (mm) | 1083 |
| Minimum ground clearance (mm) | 465 |
| Tail turning radius (mm) | 3000 |
| Track length (mm) | 4660 |
| Track gauge (mm) | 2580 |
| Track width (mm) | 3180 |
| Standard track shoe width (mm) | 600 |
| Turntable width (mm) | 2725 |
| Distance from slewing center to tail (mm) | 3000 |
| Working range | |
| Maximum digging height (mm) | 10180 |
| Maximum dumping height (mm) | 7200 |
| Maximum digging depth (mm) | 6864 |
| Maximum vertical digging depth (mm) | 5978 |
| Maximum digging distance (mm) | 10198 |
| Maximum digging distance at ground level (mm) | 10015 |
| Working device minimum turning radius (mm) | 3276 |
| Maximum lifting height of bulldozer blade (mm) | - |
| Maximum digging depth of bulldozer blade (mm) | - |
| Engine | |
| Model | QSB7(China III) |
| Type | Inline 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
| Displacement (L) | 6.7 |
| Rated power (kW/rpm) | 150/2050 |
| Hydraulic system | |
| Type of hydraulic pump | Duplex axial variable displacement plunger pump |
| Rated working flow (L/min) | 2x238 |
| Bucket | |
| Bucket capacity (m³) | 1.05 |
| Swing system | |
| Maximum swing speed (r/min) | 11 |
| Brake type | Mechanically applied and pressure released |
| Digging force | |
| Bucket arm digging force (KN) | 99/107 |
| Bucket digging force (KN) | 137/148 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 24800 |
| Ground pressure (kPa) | 47.9 |
| Traveling system | |
| Traveling motor | Axial variable displacement plunger motor |
| Traveling speed (km/h) | 3.3/5.1 |
| Traction force (KN) | 274 |
| Gradeability | 70%(35°) |
| Tank capacity | |
| Fuel tank capacity (L) | 330 |
| Cooling system (L) | 28 |
| Engine oil capacity (L) | 22 |
| Hydraulic oil tank/system capacity (L) | 270/400 |
