• Model NO.：34X-4Z
• Productivity：240m²,h
• Feeding Height：1400mm
• Vibrating Amplitude：2.4mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：White
• Stroke Length：1700 mm
• Delivery Cylinder：230 mm
• Pumping Frequency：30,20min-1
• Filling Height：1540mm
• Transport Package：Nude
• Specification：11990x2490x3900 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：87059090
• Production Capacity：100 Units, Month

ModelUnitK34X-4ZPump UnitMax. Theor. output                       m³/h120/75Max. Theor. concrete output Pressure    MPa7/11Rated working pressure                     MPa35Pumping frequency                           min-130/20Hopper    capacity                                   L540Filling height                                  mm1540Hydraulic system type opened loopDistribution valve S valveOil cylinder dia.×stroke                   mmφ130×2100Concrete cylinder    dia.×stroke          mmφ230×2100Hydraulic oil cooling Wind coolingRecommended concrete slump                    cm12~23Max. aggregate dimension                    mm40Boom    SectionStructure type 34X-4ZPlacing depth                               m33.1Max. horizontal distance                       m29.1Max. placing depth                          m20.1Slewing angle ±350°Boom number 4The length of boom section                        mm8450/6860/6870/6920Sections folding angle 90°/180°/240°/230°Pipe diameter                                mm125End hose length                          mm3000Min. height of opening placing boom        mm7900Outriggers span     (front×rear×side)  mm5920×5280×7125×7355Upper StructureUpper Structure Mass               kg15260Dimensions(L×W×H) mm9190×2500×3665
