• Model NO.：HW920
• Certification：CE, RoHS
• Condition：New
• Name：Pile Driver
• Loader Type：920
• Power Head Type：75
• Power(Kw)：40
• Impactor Type：110,150low Air Pressure
• Drilling Diameter (Cm)：110-200
• Drilling Depth(M)：1.4-2.6
• Worktable Stroke：40-70cm
• Size(M)：5*2.2*2.74
• Weight：4t
• Transport Package：Container
• Specification：6100*1850*3000mm
• Trademark：HW
• Origin：China
• Production Capacity：3000pieces,Month

HWH930L Main technical parameters

Working dimension(mm)

5910*2660*4450

Engine power(kw)

55

Transport dimension(mm)

5910*2400*2685

Drive way

four-wheel drive

Chassis body width(mm)

1850

Rotating motor torque(Nm)

1600

Vehicle weight(kg)

5060(10-8)

Mast stroke(mm)

2000

Loader model

ZL930L

Drilling depth(mm)

1650

Hydraulic hammer model

AR68/AR75/AR85

Drilling diameter(mm)

0-300

Work flow(Lmin)

40-70/50-90/60-100

Rail frame inclination0

left35right10

Impact frequency(bmp)

500-900/400-800/400-800

Adjust the angle0

±10

Work stroke(mm)

700-3130

Hydraulic system pressure(Mpa)

16-20

Drill rod diameter(mm)

68/75/85

Gear pump flow(mL/min)

40-50

Hammer force(T)

4-7/6-8/7-14

Sliding stroke left and right(mm)

0-450

Piling efficiency(mm/min)

1500/2000/2500

Height from ground(mm)

720-3100

Walking speed(km/h)

0~26

Air compressor displacement(m3)

5.6/10

Braking method

Air cap oil four-wheel disc brake

Air compressor pressure(MPa)

0.7/0.8

Engine model

YN25GBZ

Gradeability0

24
