180HP Motor Grader Gr1653 Self-Propelled Motor Grader
Shanghai Super-Above Industry Holdings Co., Ltd.- Condition：New
- Application：Railway, Mine, Farmland, Highway
Base Info
- Model NO.：GR1653 motor grader
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Medium-sized Grader
- After-Sales Service Provided：Overseas Service
- Drive Type：Rear-Axle Drive
- Engine Model：Sc7h180.1g3
- Rated Power/Speed：128kw,2000rpm
- Dimension：8900X2625X3420mm
- Operating Weight：14500kg
- Max. Gradeability：25%
- Tire Inflation Pressure：260kpa
- Working Hydraulic Pressure：20MPa
- Transmission Pressure：1.3~1.8MPa
- Tractive Force：80kn
- Maximum Lift Above Ground：450mm
- Maximum Depth of Cutting：500mm
- Moldboard Width X Height：3965X610mm
- Blade Cutting Angle：28-70degree
- Transport Package：Naked in Container
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8429209000
- Production Capacity：5000PCS,Year
Description
km/hReverse speed 5,11,23 Tractive force(f=0.75) 77 KN Max. gradeability 25 % Tire inflation pressure 260 kPa Working hydraulic pressure 20 MPa Transmission pressure 1.3~1.8 MPa Max. steering angle of front wheels ±48° Max. lean angle of front wheels ±17° Max. oscillation angle of front axle ±15° Max. oscillation angle of balance box front15°,reverse15° Frame articulation angle ±27° Min. turning radius using articulation 7.3 m Max. lift height 450 m Max. cutting depth 500 m Max. blade position angle 90° Blade cutting angle 28°-70° Circle reversing rotation 360° Moldboard width X height 3965*610 mm
