Fashion Trend Chinese Small 12ton 713h Changlin Motor Grader

Evangel Industrial (Shanghai) Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE
  • Condition：New
  • Application：Railway, Mine, Farmland, Highway
  • Transmission：Hydraulic
  • Walking Mode：Wheeled
  • Type：Small Grader

Base Info

  • Model NO.：713H
  • Transport Package：Nude Package
  • Specification：8060*3658*3370mm
  • Trademark：changlin
  • Origin：China
  • Production Capacity：100,Month

Description

SPECIFICATIONS FOR SINOMACH 132HP MOTOR GRADER 713HOverall DimensionLength*Width*Heightmm8300*2600*3370Wheel base mm5780Treadmm2120Operating weightkg12000Main  SpecificationBlade length*height*width mm3658*545*16Max lifting heightmm410Max grading depthmm560Min. turning radiusmm6600Pivot angle frame o+26Max turning angle(front wheel)o±49Oscillating angle of front axleo±16Min ground clearancemm430Traveling speed(6 forward)km/h53.4Traveling speed(3 reverse)km/h37.8EngineModel6BT5.9-C130TypeDirect injection. Turbocharged. Water coolingRated outputkW97Total exhaust of cylinderL5.9Rated speedr/min2200Max. Torque560(N.M)/1500rpmTransmission SystemModelWG180 (ZF technology)Torque Converter and TransmissionFashion Trend Chinese Small 12ton 713h Changlin Motor Grader
