• Material：High Manganese Steel, Tungsten Carbide
• Use：Coal Mining, Quarry Drilling or Well Drilling
• Transfer：Air,Sea,Express
• Color：Request
• Power Type：Air Compressor
• Product Name：Rock Drill,Jack Hammer
• Working Pressure：0.4-0.8MPa
• Air Consumption：≤26(L,S)
• Transport Package：Wooden Box or as Customers Inquire
• Specification：G7, G10, G11, G15, MO-2B
• Trademark：PANDA
• Origin：Shandong China
• HS Code：84303900
• Production Capacity：2000 Sets , Week

Basic Info.

Material High Manganese Steel, Tungsten Carbide Use Coal Mining, Quarry Drilling or Well Drilling Transfer Air/Sea/Express Color Request Power Type Air Compressor Product Name Rock Drill/Jack Hammer Working Pressure 0.4-0.8MPa Air Consumption ≤26(L/S) Transport Package Wooden Box or as Customers Inquire Specification G7, G10, G11, G15, MO-2B Trademark PANDA Origin Shandong China HS Code 84303900 Production Capacity 2000 Sets / Week

Product Description

Product Description:

Compared with the same other type pick,  Air Pick for Sale is lighter, more flexible and convenient operation. It's suitable for operating all around of work, especially in narrow space, upper or climbing direction.

It can stop working automatically when the solid object is broken. It's widely used in coal mining, soft rock, digging pits for post brackets, digging slots, breaking concrete, frozen earth in construction and installation engineering or constructing works in casting industries.

Main Characteristics of  Air Pick for Sale.

1, Strictly control of material using, meet international requested standards.

2, Import bearing parts and use high wear-resisting precision castings to greatly prove the life of the product.

3, Belongs to a kind of pneumatic instrument combined with the mature international technology.

4, Hand-held pneumatic tool, use compressed air to push the piston reciprocating movement, keep the pick up to the impact.

Specification:

Type	G7	G10	G11	G15
Weight	7.2(Kg)	10.9(Kg)	11.5(Kg)	12(Kg)
Length	570(mm)	575(mm)	575(mm)	580(mm)
Cylinder Dia	35mm	38(mm)	38(mm)	42(mm)
Rammar Stroke	120mm	155(mm)	155(mm)	1.12(Kg)
Rammar Weight	0.8Kg	0.9(Kg)	0.9(Kg)	0.9(Kg)
Working Pressure	0.4-0.5(Mpa)	0.4-0.5(Mpa)	0.6-0.7(Mpa)	0.6-0.7(Mpa)
Impact Energy	≥43(J)	≥43(J)	≥43(J)	≥55(J)
Impact Frequency	≥18(Hz)	≥18(Hz)	≥17(Hz)	≥18(Hz)
Air Consumption	≤20(L/s)	≤20(L/s)	≤26(L/s)	≤26(L/s)
Air Pipe Inner Dia	16(mm)	16(mm)	16(mm)	16(mm)

FAQ:

Q1: Can I have a sample for testing?

A:Samples are still to be paid but discounted price can be provided.

Q2: Do you have the inspection procedures?

A:100% strict inspection and testing for every order before packing.

Q3: How can i get the after sale services?

A:Free replacement will provide once the problems casued by our product quality.

Q4: Can I have a visit to your factory before the order?


A: Sure, welcome, here is our address: Yantai, Shandong.
