• Model NO.：L26-B3
• Walking Mode：Wheeled
• Type：Small Loader
• Transport Package：Nude Package
• Specification：6 ton
• Trademark：SINOMADA
• Origin：China
• HS Code：8429521200
• Production Capacity：50000pieces,Year

Basic Info.

Model NO. L26-B3 Walking Mode Wheeled Type Small Loader Transport Package Nude Package Specification 6 ton Trademark SINOMADA Origin China HS Code 8429521200 Production Capacity 50000pieces/Year

Product Description

Best Price World Top 1 Front Wheel Loader 2Ton L26-B3Power System
YTO LR China-III low-speed engine features low malfunction rate, low noise, and low fuel consumption under composite working condition.
Good site adaptability
The fixed shaft 428 transmission with 4 forward gears and 2 reverse gears achieves more extensive site adaptability.
Good heat dissipation performance
The number of engine fan blades is adjusted from 7 to 9 to increase the airflow output by 10~15% and achieve better heat dissipation performance. The radiator structure is adjusted to eliminate overheating during long-distance driving and further broaden the application scope.

Parameter name	L26-B3 SG (Sandstone version)	L26-B3 CH (Coal version)	L26-B3 MW(Mining version)
Performance parameters
Operating weight (Kg)	6200	6200	5600
Maximum dumping height (mm)	2460 (Standard boom)2850 (Long Boom)	2700 (Long Boom)	2460 (Standard boom)
Dumping reach (mm)	850 (Standard boom) 865 (Long Boom)	1000 (Long Boom)	850 (Standard boom)
Maximum breakout force (kN)	55	50	55
Total cycle time (s)	8	8	8
Engine
Engine model	LR4B3	LR4B3	LR4B3
Rated power/rated speed (kW/rpm)	62.5/2200	62.5/2200	62.5/2200
Overall dimensions
Overall dimensions of machine (mm)	6120*2078*2850	6210*2078*2850	5590*2078*2450
Driving performance
Forward speed (km/h)	F1:0-8, F2:0-11.5, F3:0-20, F4:0-28	F1:0-8, F2:0-11.5, F3:0-20, F4:0-28	F1:0-10, F2:0-24
Reversing speed (km/h)	R1:0-10, R2:0-24	R1:0-10, R2:0-24	R1:0-10, R2:0-24
Chassis System
Wheelbase (mm)	2270	2270	2270
