• Model NO.：XE65DA
• Drive Type：Electric Drive
• Bucket Capacity：0.25cbm
• Size：Medium-Sized
• Certification：ISO9001: 2000
• Condition：New
• Transport Package：Nude Package
• Specification：6ton
• Trademark：Sinomada
• Origin：China
• HS Code：8429521200
• Production Capacity：50000pieces,Year

Basic Info.

Model NO. XE65DA Drive Type Electric Drive Bucket Capacity 0.25cbm Size Medium-Sized Certification ISO9001: 2000 Condition New Transport Package Nude Package Specification 6ton Trademark Sinomada Origin China HS Code 8429521200 Production Capacity 50000pieces/Year

Product Description

Construction Machinery Small Chinese Crawler Excavator Machine XE65DA

Selling point:



1.Enlarging and widening the chassis, the solid chassis makes the excavation more stable and the lifting operation easier.



2.Bulldozing shovel with standard hydraulic lock, long time operation can not drop the shovel, high safety.



3.Higher efficiency and large capacity bucket, new optimization of bucket shape, more efficient unloading.



4.Automatic idle function automatically reduces engine speed during operating wait.

Sales model		Unit	XE65DA
Operating weight		Kg	6150
Bucket capacity		m³	0.25
Engine	Model	/	4TNV94L
	No. of cylinders	/	4
	Rated power	kw/rpm	36.2/2100
	Displacement	L	3.054
Main performance	Travel speed	km/h	4.2/2.4
	Swing speed	r/min	10
	Gradeability	°	35
	Ground pressure	kPa	32.1
	Bucket digging force	kN	48.3
	Arm digging force	kN	32.5
	Maximum tractive force	kN	52
Hydraulic system	Rated flow of main pump	L/min	160
	Main safety valve pressure	MPa	24.5
	Travel system pressure	MPa	24.5
	Swing system pressure	MPa	24
	Pilot system pressure	MPa	3.5
Oil Capacity	Fuel tank capacity	L	110
	Hydraulic tank capacity	L	85
	Engine oil capacity	L	12
Appearance size	A Overall length	mm	5860
	B Overall width	mm	2040
	C Overall height	mm	2585
	D Width of platform	mm	1780
	F Overall width of chassis	mm	2040
	G Track width	mm	400
	I Track gauge	mm	1600
