Shantui 47 Ton Heavy Duty Excavator Se470LC Hot Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：GM Excavator
- Bucket：Backhoe
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE470LC
- Drive Type：Electric Drive
- Bucket Capacity：0.55~2.5(2.2)Cbm
- Size：Large-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Maximum Digging Height (mm)：10785
- Maximum Dumping Height (mm)：7600
- Maximum Digging Depth (mm)：7815
- Maximum Vertical Digging Depth (mm)：6295
- Maximum Digging Distance (mm)：12040
- Maximum Digging Distance at Ground Level：11830
- Working Device Minimum Turning Radius (M：4840
- Engine Model：Qsm11(China III)
- Displacement (L)：10.8
- Rated Power (Kw/Rpm)：250,2000
- Rated Working Flow (L/Min)：360*2+27
- Maximum Swing Speed (R/Min)：10
- Bucket Digging Force (Kn)：288.5
- Operating Weight (Kg)：46800
- Ground Pressure (Kpa)：81.9
- Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification：12110 *3745*3360mm
- Trademark：shantui
- Origin：China
- Production Capacity：300piece,Month
Description
Basic Info.
Model NO. SE470LC Drive Type Electric Drive Bucket Capacity 0.55~2.5(2.2)Cbm Size Large-Scale Certification CE, ISO9001: 2000 Condition New Maximum Digging Height (mm) 10785 Maximum Dumping Height (mm) 7600 Maximum Digging Depth (mm) 7815 Maximum Vertical Digging Depth (mm) 6295 Maximum Digging Distance (mm) 12040 Maximum Digging Distance at Ground Level 11830 Working Device Minimum Turning Radius (M 4840 Engine Model Qsm11(China III) Displacement (L) 10.8 Rated Power (Kw/Rpm) 250/2000 Rated Working Flow (L/Min) 360*2+27 Maximum Swing Speed (R/Min) 10 Bucket Digging Force (Kn) 288.5 Operating Weight (Kg) 46800 Ground Pressure (Kpa) 81.9 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 12110 *3745*3360mm Trademark shantui Origin China Production Capacity 300piece/MonthProduct Description
Shantui 47 Ton Heavy Duty Excavator SE470LC Hot SaleCHARACTERISTICEnhanced working device
The design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
Enhanced working deviceThe design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
Spacious and comfortable operating environmentThe colors of the all-injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.
The control devices are reasonably arranged to realize large space, broad vision, and convenient and comfortable operations.
The high-power A/C system and the air cushioned seat guarantee comfortable driving/riding.
Drive sprockets, idlers, track rollers, carrier rollers, and tracks30 years of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and world's leading technologies.
The world's sophisticated forging and heat treatment processes guarantee stable and reliable quality.
Intelligent electronic control and optimal power controlThe intelligent control system realizes the optimal match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.
The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Quick and convenient maintenancesThe backward-openable engine hood features handy opening, large opening angle, and easy maintenances.
The engine oil filter element is arranged remotely at the right door to ease the maintenances.
The high-precision fuel filter element is centrally arranged at the left door to ease the maintenances.
The filling of coolant and the replacement of air filter element are easily accessible.
The parallel radiator effectively avoids the overheating and eases the cleaning.
Optional equipment of machineRefueling pump
Cab warning lamp
Cab ceiling lamp
Cab front upper protective net
Rubber track
Narrow bucket
Cab overhead protective net (Standard equipment)
Cab front lower protective net (Standard equipment)
Optional attachmentsBreaking hammer, ripper, timber grab, stone grab, quick change coupling, hydraulic tamper, and breaking hammer pipeline.
PARAMETER| Comparative item | SE470LC (Standard version) |
| Overall dimensions | |
| Overall length (mm) | 12110 |
| Ground length (During transport) (mm) | 6660 |
| Overall height (To the top of boom) (mm) | 3745 |
| Overall width (mm) | 3360 |
| Overall height (To top of cab) (mm) | 3330 |
| Ground clearance of counterweight (mm) | 1395 |
| Minimum ground clearance (mm) | 590 |
| Tail turning radius (mm) | 3720 |
| Track length (mm) | 5315 |
| Track gauge (mm) | 2760 |
| Track width (mm) | 3360 |
| Standard track shoe width (mm) | 600 |
| Turntable width (mm) | 3190 |
| Distance from slewing center to tail (mm) | 3675 |
| Working range | |
| Maximum digging height (mm) | 10785 |
| Maximum dumping height (mm) | 7600 |
| Maximum digging depth (mm) | 7815 |
| Maximum vertical digging depth (mm) | 6295 |
| Maximum digging distance (mm) | 12040 |
| Maximum digging distance at ground level (mm) | 11830 |
| Working device minimum turning radius (mm) | 4840 |
| Maximum lifting height of bulldozer blade (mm) | - |
| Maximum digging depth of bulldozer blade (mm) | - |
| Engine | |
| Model | QSM11(China III) |
| Type | Inline 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
| Displacement (L) | 10.8 |
| Rated power (kW/rpm) | 250/2000 |
| Hydraulic system | |
| Type of hydraulic pump | Variable displacement duplex plunger pump |
| Rated working flow (L/min) | 360×2+27 |
| Bucket | |
| Bucket capacity (m³) | 0.55~2.5(2.2) |
| Swing system | |
| Maximum swing speed (r/min) | 10 |
| Brake type | Mechanically applied and pressure released |
| Digging force | |
| Bucket arm digging force (KN) | 242 |
| Bucket digging force (KN) | 288.5 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 46800 |
| Ground pressure (kPa) | 81.9 |
| Traveling system | |
| Traveling motor | Axial variable displacement plunger motor |
| Traveling speed (km/h) | 3.3/5.6 |
| Traction force (KN) | 364 |
| Gradeability | 70%(35°) |
| Tank capacity | |
| Fuel tank capacity (L) | 620 |
| Cooling system (L) | 34 |
| Engine oil capacity (L) | 35 |
| Hydraulic oil tank/system capacity (L) | 366/460 |
