320HP Hydraulic Crawler Bulldozer From China

Shanghai Super-Above Industry Holdings Co., Ltd.
  • Transmission：Power Transmission
  • Walking Mode：Crawler

Base Info

  • Model NO.：SAB32
  • Load and Unload Method：Rotary
  • Engine Power：>515kw
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Color：Yellow
  • Rated Power：235kw,2000rpm
  • Piston Displacement：14.01L
  • Width of Track Shoes：560mm
  • Pitch：228.6mm
  • Operating Weight：4520 Kg
  • Transport Package：Naked in Container
  • Specification：CE
  • Trademark：Super-above
  • Origin：Jiangsu, China
  • HS Code：8474390000
  • Production Capacity：10000PC,Year

Description

Power transmitting systemTorque converter3-element, 1 stage, 1 phaseTransmissionPlanetary gear,multi-disc clutch,power shift,forced lubricationMain driveSpiral bevel gear, splash lubrication,single-stage speed reductionSteering clutchWet, Multi-disc, spring loaded, hydraulic separated,hydraulic controlSteering brakeWet, floating band type,  foot brake with hydraulic boosterFinal drive2-stage speed reduction of spur gear, splash lubricationBlade blade type Straight-tiltAngleSemi-U bladeDozing capacity(m3)10611.9Blade  height x width (mm)1590 x 43101140 x 50001710 x 4130Max. Drop below ground(mm)560630560Max. Tilt adjustment(mm)7355001000Operating weight(kg)452049324924Efficiency(m3/h)580350690TRAVEL SPEEDGear1st2nd3rdFoward(km/h)0~3.60~6.60~11.5Reverse(km/h)0~4.40~7.80~13.5

FEATURES & APPLICATION
The widened track shoes guarantee low ground pressure, high stability, and powerful traction to fulfill precise horizontal operations.
The wet type steering clutch and brake can prolong the service life and are interlinked with each other to guarantee the rapid and
flexible steering controls by joysticks.
It can complete the digging, handling, and landfill operations of earthworks and is suitable for the engineering constructions for
roads, farms, water conservancy projects, municipal projects, and energy projects.
