Oriemac Clg856h 3cbm Telescopic Wheel Loader
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：ISO
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：clg856h
- Type：Medium-sized Loader
- Bucket Capacity：3m3
- Engine：Diesel Engine
- Rated Power：162kw
- Operating Weight：16500kg
- Dump Height：3200mm
- X. Traction Force：165kn
- Transport Package：Nude
- Specification：8185x3000x3465mm
- Trademark：liugong
- Origin：Guangxi
- Production Capacity：100unit,Month
Description
Enginee
Model
C6121
Type
Vertical,water cooled,four-stroke,direct injection
Rated power
158KW
Rated speed
2200rpm
Rated fuel consumption
220g/Kw.h
Main Technical Specification
Rated load
5000Kg
Operating weight
16500Kg
Rated bucket capacity
3m3
Max. breakout force
165kN
Max. dump clearance
3200mm
Dump reach
1180mm
Dump angle at any position
45°
Digging depth(with bucket bottom horizontal)
212mm
Min. turning radius
-----Outside of bucket
6300mm
-----Outside of rear wheel
5795mm
Oscillating angle of rear axle
±11°
Lifting time of bucket
≤5.8s
Lowering time of bucket
≤3.77s
Dumping time
≤1.43s
