• Model NO.：XE150WB
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：87059091
• Production Capacity：10000,Year

  UnitParametersOperating weight Kg15318Bucket capacity M³0.58 Engine model/QSB4.5EngineOutput power of engineKw/r/min104/2000 Max.torque/engineN.m586 DisplacementL4.5 Fuel tank capacityL250 Rated flow of main pumpL/min2x160 Pressure of main safety valveMpa31.4/34.3performance parameterHydraulic tank capacityL135 Slewing speedr/min13.7 Digging capacity of tcuketKN60 Digging capacity of tcuket rodKN65 Min.turning radiusmm6500 Travel speedKm/h45 Gradient capability%70 A Total lengthmm6482 B Total widthmm2552 C Total heigthmm3158Working scope Counterweight ground clearancemm1230 Min.ground clearancemm359 Min.tail swing radiusmm2300 Wheelbasemm2800 Track gaugemm1920 Total width of chassismm2495 Distance between front axle and turning centermm1700 Hood heightmm2430 The maximum digging depth of dozermm112 Dozer (width / height)mm2495x564 A Max.digging heightmm8296Working scopeB Max.unloading heightmm8085 C Max.digging depthmm9150 D Digging depth at the range of 8feets horizontallymm6684 E Max.vertical digging depthmm5040 F Max.digging radiusmm4825 G Max.swing heightmm515





Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2019, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.
